85
STR-DG910
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1231-379-A DISPLAY BOARD, COMPLETE
************************
< CAPACITOR >
C110 1-162-286-31 CERAMIC 220PF 10% 50V
C111 1-162-286-31 CERAMIC 220PF 10% 50V
C112 1-162-286-31 CERAMIC 220PF 10% 50V
C114 1-127-888-11 CERAMIC 0.1uF 10% 50V
C115 1-126-964-11 ELECT 10uF 20% 50V
C144 1-127-888-11 CERAMIC 0.1uF 10% 50V
C145 1-127-888-11 CERAMIC 0.1uF 10% 50V
C147 1-162-286-31 CERAMIC 220PF 10% 50V
C148 1-126-964-11 ELECT 10uF 20% 50V
C149 1-162-286-31 CERAMIC 220PF 10% 50V
C160 1-127-888-11 CERAMIC 0.1uF 10% 50V
C162 1-127-888-11 CERAMIC 0.1uF 10% 50V
C164 1-162-286-31 CERAMIC 220PF 10% 50V
C165 1-126-964-11 ELECT 10uF 20% 50V
C171 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
* CN105 1-691-406-11 CONNECTOR, BOARD TO BOARD 7P
CNS102 1-784-788-11 CONNECTOR, FFC 27P
< DIODE >
D105 6-501-539-01 LED SELK5E20C-DTP15
(MULTI CHANNEL DECODING)
< VACUUM FLUORESCENT DISPLAY >
FL101 1-519-927-11 VACUUM FLUORESCENT DISPLAY
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-243-51 IC TC74ACT08P
IC103 6-600-349-31 IC NJL24H400A (IR)
< TRANSISTOR >
Q110 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R101 1-249-409-11 CARBON 220 5% 1/4W
R102 1-249-411-11 CARBON 330 5% 1/4W
R103 1-249-413-11 CARBON 470 5% 1/4W
R104 1-249-415-11 CARBON 680 5% 1/4W
R105 1-247-831-11 CARBON 1K 5% 1/4W
R106 1-249-419-11 CARBON 1.5K 5% 1/4W
R107 1-249-421-11 CARBON 2.2K 5% 1/4W
R108 1-249-409-11 CARBON 220 5% 1/4W
R109 1-249-411-11 CARBON 330 5% 1/4W
R110 1-249-413-11 CARBON 470 5% 1/4W
R115 1-247-807-31 CARBON 100 5% 1/4W
R116 1-247-807-31 CARBON 100 5% 1/4W
R117 1-247-807-31 CARBON 100 5% 1/4W
R118 1-249-440-11 CARBON 82K 5% 1/4W
R119 1-247-807-31 CARBON 100 5% 1/4W
R120 1-249-393-11 CARBON 10 5% 1/4W F
R122 1-247-804-11 CARBON 75 5% 1/4W
R131 1-249-421-11 CARBON 2.2K 5% 1/4W
R197 1-249-387-81 CARBON 3.3 5% 1/4W F
R198 1-249-387-81 CARBON 3.3 5% 1/4W F
< ROTARY ENCODER >
RV101 1-418-817-11 ENCODER, ROTARY (INPUT SELECTOR)
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S101 1-771-410-21 SWITCH, TACTILE (DIRECT)
S102 1-771-410-21 SWITCH, TACTILE (AUTO CAL)
S103 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S104 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S105 1-771-410-21 SWITCH, TACTILE (MUSIC)
S106 1-771-410-21 SWITCH, TACTILE (MOVIE)
S107 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S108 1-771-410-21 SWITCH, TACTILE (2CH)
S109 1-771-410-21 SWITCH, TACTILE (CATEGORY +) (US,CND)
S109 1-771-410-21 SWITCH, TACTILE (SUR BACK DECODING)
(EXCEPT US,CND)
S110 1-771-410-21 SWITCH, TACTILE (CATEGORY –) (US,CND)
S110 1-771-410-21 SWITCH, TACTILE (SLEEP) (EXCEPT US,CND)
S111 1-771-410-21 SWITCH, TACTILE (CATEGORY MODE)
(US,CND)
S111 1-771-410-21 SWITCH, TACTILE (DIMMER)
(EXCEPT US,CND)
S112 1-771-410-21 SWITCH, TACTILE (MEMORY/ENTER)
*************************************************************
9 A-1237-655-A HDMI RE BOARD, COMPLETE (for SERVICE)
************************
< CAPACITOR >
C3501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3509 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3511 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3514 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3516 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3517 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3519 1-126-210-21 ELECT CHIP 220uF 20% 4V
C3520 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3521 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3522 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3523 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3524 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3525 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3526 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3527 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
