98
STR-DG910
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TERMINAL BOARD >
TM601 1-780-214-11 TERMINAL BOARD (SP) (2P)
(SPEAKERS CENTER)
TM602 1-780-364-11 TERMINAL BOARD (SP) (8P)
(SPEAKERS SURROUND BACK,SURROUND)
*************************************************************
POWER KEY BOARD
*****************
< CONNECTOR >
* CN102 1-691-408-11 CONNECTOR, BOARD TO BOARD 7P
< RESISTOR >
R111 1-249-415-11 CARBON 680 5% 1/4W
R112 1-247-831-11 CARBON 1K 5% 1/4W
R113 1-249-419-11 CARBON 1.5K 5% 1/4W
< ROTARY ENCODER >
RV103 1-418-817-11 ENCODER, ROTARY (– TUNING +)
RV104 1-418-817-11 ENCODER, ROTARY (– TONE +)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (?/1)
S113 1-771-410-21 SWITCH, TACTILE (TUNING MODE)
S114 1-771-410-21 SWITCH, TACTILE (TONE MODE)
S115 1-771-410-21 SWITCH, TACTILE (SPEAKERS (OFF/A/B/A+B))
*************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C2850 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2851 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2860 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2861 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CC101 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EXCEPT US,CND)
CC102 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EXCEPT US,CND)
CC111 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EXCEPT US,CND)
CC112 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EXCEPT US,CND)
< CONNECTOR >
CNP285 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
* CNP286 1-564-508-11 PLUG, CONNECTOR 5P
< DIODE >
D2881 8-719-404-50 DIODE MA111-TX
D2891 8-719-404-50 DIODE MA111-TX
< TRANSISTOR >
Q2880 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q2890 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R2871 1-249-397-11 CARBON 22 5% 1/4W F
R2872 1-249-399-11 CARBON 33 5% 1/4W F
R2873 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2881 1-249-397-11 CARBON 22 5% 1/4W F
R2882 1-249-399-11 CARBON 33 5% 1/4W F
R2883 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
RR101 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
RR102 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
RR111 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
RR112 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
< RELAY >
RY2881 1-755-170-11 RELAY (12V)
RY2891 1-755-170-11 RELAY (12V)
< TERMINAL BOARD >
TM2880 1-780-364-11 TERMINAL BOARD (SP) (8P)
(SPEAKERS FRONT A,FRONT B)
*************************************************************
A-1231-380-A STANDBY BOARD, COMPLETE (US,CND)
A-1236-403-A STANDBY BOARD, COMPLETE (AEP,UK)
A-1236-404-A STANDBY BOARD, COMPLETE (E2)
*************************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C913 1-127-888-11 CERAMIC 0.1uF 10% 50V
C914 1-127-888-11 CERAMIC 0.1uF 10% 50V
C915 1-126-943-11 ELECT 2200uF 20% 25V
C916 1-126-942-61 ELECT 1000uF 20% 25V
C920 1-127-888-11 CERAMIC 0.1uF 10% 50V
C921 1-127-888-11 CERAMIC 0.1uF 10% 50V
C922 1-127-888-11 CERAMIC 0.1uF 10% 50V
(US,CND)
C924 1-126-960-11 ELECT 1uF 20% 50V
C951 1-127-888-11 CERAMIC 0.1uF 10% 50V
C952 1-126-942-61 ELECT 1000uF 20% 25V
(EXCEPT E2)
C952 1-126-943-11 ELECT 2200uF 20% 25V
(E2)
C954 1-128-547-11 ELECT 6800uF 20% 16V
< AC OUTLET >
0 CN005 1-251-718-11 OUTLET (2 GANG), AC (AC OUTLET) (US,CND)
< CONNECTOR >
CNP002 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P (E2)
* CNP802 1-564-509-11 PLUG, CONNECTOR 6P
* CNP804 1-564-506-11 PLUG, CONNECTOR 3P
* CNP805 1-564-506-11 PLUG, CONNECTOR 3P
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP902 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
MAIN POWER KEY STANDBYSPEAKER
