57
STR-K885
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R761 1-216-844-11 METAL CHIP 82K 5% 1/10W
R763 1-216-818-11 METAL CHIP 560 5% 1/10W
0 R764 1-249-399-11 CARBON 33 5% 1/4W F
0 R765 1-249-399-11 CARBON 33 5% 1/4W F
0 R766 1-234-182-11 ENCAPSULATED COMPONENT
0 R767 1-249-393-11 CARBON 10 5% 1/4W F
0 R768 1-249-389-11 CARBON 4.7 5% 1/4W F
R769 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R770 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R771 1-240-855-91 CARBON 6.2K 5% 1/4W F
R772 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R773 1-216-841-11 METAL CHIP 47K 5% 1/10W
R775 1-216-843-11 METAL CHIP 68K 5% 1/10W
R778 1-216-835-11 METAL CHIP 15K 5% 1/10W
R780 1-216-833-11 METAL CHIP 10K 5% 1/10W
R790 1-216-845-11 METAL CHIP 100K 5% 1/10W
R791 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W F
0 R793 1-249-404-00 CARBON 82 5% 1/4W F
0 R794 1-215-868-00 METAL OXIDE 680 5% 1W F
0 R802 1-249-409-11 CARBON 220 5% 1/4W F
0 R803 1-249-389-11 CARBON 4.7 5% 1/4W F
R804 1-216-833-11 METAL CHIP 10K 5% 1/10W
R806 1-216-837-11 METAL CHIP 22K 5% 1/10W
R840 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R843 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
R844 1-216-837-11 METAL CHIP 22K 5% 1/10W
0 R910 1-240-877-11 FUSIBLE 0.15 5% 1/2W F
R3010 1-216-841-11 METAL CHIP 47K 5% 1/10W
(SP, SP6, AUS)
R3011 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
(SP, SP6, AUS)
R3012 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
(SP, SP6, AUS)
R3013 1-216-841-11 METAL CHIP 47K 5% 1/10W
(SP, SP6, AUS)
R3020 1-216-841-11 METAL CHIP 47K 5% 1/10W
(SP, SP6, AUS)
R3021 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
(SP, SP6, AUS)
R3022 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
(SP, SP6, AUS)
R3023 1-216-841-11 METAL CHIP 47K 5% 1/10W
(SP, SP6, AUS)
R3025 1-216-809-11 METAL CHIP 100 5% 1/10W
(AUS)
< RESISTOR >
0 RR11 1-249-393-11 CARBON 10 5% 1/4W F
(AUS)
0 RR12 1-249-393-11 CARBON 10 5% 1/4W F
(AUS)
0 RR13 1-249-393-11 CARBON 10 5% 1/4W F
(AUS)
0 RR14 1-249-393-11 CARBON 10 5% 1/4W F
(AUS)
0 RR15 1-249-393-11 CARBON 10 5% 1/4W F
(AUS)
0RR16 1-249-393-11 CARBON 10 5% 1/4W F
(AUS)
0RR17 1-249-393-11 CARBON 10 5% 1/4W F
(AUS)
0RR18 1-249-393-11 CARBON 10 5% 1/4W F
(AUS)
< RELAY >
RY560 1-755-267-11 RELAY
RY601 1-755-170-11 RELAY (12V)
RY610 1-755-170-11 RELAY (12V)
RY701 1-755-170-11 RELAY (12V)
RY791 1-755-170-11 RELAY (12V)
< TERMINAL >
TB001 1-780-449-11 BANANA-PUSH TERMINAL BOARD (8P)
(FRONT,SURROUND)
< TERMINAL >
TM603 1-780-451-11 BANANA-PUSH TERMINAL BOARD (4P)
(SURROUND BACK,CENTER)
*************************************************************
POWER KEY BOARD
****************
< CONNECTOR >
* CN103 1-691-670-11 CONNECTOR, BOARD TO BOARD 5P
< RESISTOR >
R111 1-249-415-11 CARBON 680 5% 1/4W
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (?/1)
S115 1-771-410-21 SWITCH, TACTILE (AUTO CAL)
*************************************************************
A-1222-747-A STANDBY BOARD
**************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C913 1-127-888-11 CERAMIC 0.1uF 10% 50V
C914 1-127-888-11 CERAMIC 0.1uF 10% 50V
C915 1-126-943-11 ELECT 2200uF 20% 25V
C916 1-126-942-61 ELECT 1000uF 20% 25V
C920 1-127-888-11 CERAMIC 0.1uF 10% 50V
C921 1-127-888-11 CERAMIC 0.1uF 10% 50V
C924 1-126-960-11 ELECT 1uF 20% 50V
C950 1-126-936-11 ELECT 3300uF 20% 16V
< CONNECTOR >
CNP002 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P (E51)
* CNP802 1-564-509-11 PLUG, CONNECTOR 6P
* CNP804 1-564-506-11 PLUG, CONNECTOR 3P
* CNP805 1-564-506-11 PLUG, CONNECTOR 3P
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP902 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
POWER KEYMAIN STANDBY
Ver. 1.1
