58
STR-K885
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* CNP903 1-564-508-11 PLUG, CONNECTOR 5P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-991-33 DIODE 1SS133T-77
0 D920 6-500-522-11 DIODE 10EDB40-TA2B5
0 D921 6-500-522-11 DIODE 10EDB40-TA2B5
0 D922 6-500-522-11 DIODE 10EDB40-TA2B5
0 D923 6-500-522-11 DIODE 10EDB40-TA2B5
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q921 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
0 R810 1-243-634-91 FUSIBLE 0.22 5% 1/2W
0 R811 1-243-634-91 FUSIBLE 0.22 5% 1/2W
R902 1-247-871-91 CARBON 47K 5% 1/4W
R903 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R904 1-249-381-11 CARBON 1 5% 1/4W F
R921 1-247-871-91 CARBON 47K 5% 1/4W
R922 1-247-863-91 CARBON 22K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-541-11 RELAY
< TRANSFORMER >
0 T902 1-443-517-11 POWER TRANSFORMER (EXCEPT E51)
0 T902 1-443-520-11 POWER TRANSFORMER (E51)
*************************************************************
VIDEO BOARD
***********
< CAPACITOR >
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-947-11 ELECT 47uF 20% 35V
C213 1-126-947-11 ELECT 47uF 20% 35V
C214 1-127-888-11 CERAMIC 0.1uF 10% 50V
C215 1-127-888-11 CERAMIC 0.1uF 10% 50V
C220 1-126-947-11 ELECT 47uF 20% 35V
C221 1-126-947-11 ELECT 47uF 20% 35V
C223 1-135-799-11 CERAMIC 0.47uF 50V
C224 1-135-799-11 CERAMIC 0.47uF 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-126-964-11 ELECT 10uF 20% 50V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-964-11 ELECT 10uF 20% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-964-11 ELECT 10uF 20% 50V
C316 1-126-964-11 ELECT 10uF 20% 50V
C330 1-127-888-11 CERAMIC 0.1uF 10% 50V
C331 1-127-888-11 CERAMIC 0.1uF 10% 50V
C337 1-126-947-11 ELECT 47uF 20% 35V
C338 1-126-947-11 ELECT 47uF 20% 35V
C341 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNP202 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CNP203 1-564-507-11 PLUG, CONNECTOR 4P
CNS207 1-784-774-11 CONNECTOR, FFC 13P
< DIODE >
D203 8-719-991-33 DIODE 1SS133T-77
D204 8-719-991-33 DIODE 1SS133T-77
< IC >
IC203 6-701-890-01 IC NJM2595D
IC304 6-707-363-01 IC NJM2586AL
0 IC804 8-759-245-79 IC TA79005S
0 IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-794-978-11 JACK, PIN 3P (DVD,VIDEO 1,SAT)
J201 1-815-043-11 JACK, PIN 2P (VIDEO 1,MONITOR)
J301 1-816-592-11 JACK, PIN 9P (SAT IN,DVD IN,VIDEO IN)
J302 1-815-360-11 JACK, PIN 3P (MONITOR OUT)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
R308 1-247-804-11 CARBON 75 5% 1/4W
R309 1-247-804-11 CARBON 75 5% 1/4W
R310 1-247-804-11 CARBON 75 5% 1/4W
R311 1-247-804-11 CARBON 75 5% 1/4W
R312 1-247-804-11 CARBON 75 5% 1/4W
*************************************************************
A-1222-706-A VIDEO 3 BOARD
*************
< CAPACITOR >
C293 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
