Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
67
STR-KM5/KM7
R2854 1-218-945-11 METAL CHIP 220 5% 1/16W
R2855 1-250-468-11 METAL CHIP 75 1% 1/16W
R2856 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2857 1-218-941-81 METAL CHIP 100 5% 1/16W
R2858 1-218-941-81 METAL CHIP 100 5% 1/16W
R2859 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
* R2860 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
R2861 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2863 1-218-933-11 METAL CHIP 22 5% 1/16W
R2864 1-218-933-11 METAL CHIP 22 5% 1/16W
R2865 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2866 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2867 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2868 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2872 1-218-933-11 METAL CHIP 22 5% 1/16W
R2875 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2876 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2878 1-218-933-11 METAL CHIP 22 5% 1/16W
R2879 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2880 1-218-933-11 METAL CHIP 22 5% 1/16W
R2881 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2882 1-218-933-11 METAL CHIP 22 5% 1/16W
R2886 1-250-519-11 METAL CHIP 10K 1% 1/16W
* R2889 1-250-491-11 METAL CHIP 680 1% 1/16W
R2895 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2897 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2898 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2899 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2901 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2906 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2910 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2912 1-218-941-81 METAL CHIP 100 5% 1/16W
R2914 1-218-949-11 METAL CHIP 470 5% 1/16W
R2915 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2919 1-218-941-81 METAL CHIP 100 5% 1/16W
R2925 1-218-937-11 METAL CHIP 47 5% 1/16W
R2929 1-218-941-81 METAL CHIP 100 5% 1/16W
R2930 1-218-941-81 METAL CHIP 100 5% 1/16W
R2932 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2933 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2939 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2940 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2941 1-250-519-11 METAL CHIP 10K 1% 1/16W
R2943 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2945 1-218-990-81 SHORT CHIP 0
R2947 1-218-990-81 SHORT CHIP 0
R2948 1-218-990-81 SHORT CHIP 0
R2949 1-218-990-81 SHORT CHIP 0
R2951 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2952 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2957 1-218-941-81 METAL CHIP 100 5% 1/16W
R2958 1-218-941-81 METAL CHIP 100 5% 1/16W
R2959 1-218-941-81 METAL CHIP 100 5% 1/16W
R2960 1-218-941-81 METAL CHIP 100 5% 1/16W
R2962 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2963 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2979 1-218-941-81 METAL CHIP 100 5% 1/16W
R2980 1-218-990-81 SHORT CHIP 0
R2983 1-218-941-81 METAL CHIP 100 5% 1/16W
R2984 1-218-941-81 METAL CHIP 100 5% 1/16W
R2985 1-218-941-81 METAL CHIP 100 5% 1/16W
R2986 1-218-941-81 METAL CHIP 100 5% 1/16W
R2987 1-218-941-81 METAL CHIP 100 5% 1/16W
R2989 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2992 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2993 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2994 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2995 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2996 1-218-990-81 SHORT CHIP 0
R2997 1-218-937-11 METAL CHIP 47 5% 1/16W
R2998 1-218-937-11 METAL CHIP 47 5% 1/16W
R2999 1-218-937-11 METAL CHIP 47 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB2010 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB2102 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2103 1-234-375-21 RES, NETWORK 1K (1005X4)
RB2104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2109 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2119 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2121 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2123 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2124 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2125 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2126 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2127 1-234-372-11 RES, NETWORK 100 (1005X4)
< VIBRATOR >
X2101 1-781-646-21 VIBRATOR, CERAMIC (4MHz)
X2800 1-814-242-11 VIBRATOR, CRYSTAL (25MHz)
X2801 1-814-350-11 QUARTZ CRYSTAL UNITS (24.576MHz)
*************************************************************
A-1851-750-A DISPLAY BOARD, COMPLETE
(EXCEPT KM5: US)
A-1990-466-A DISPLAY BOARD, COMPLETE (KM5: US)
***********************
< CAPACITOR >
C102 1-124-589-11 ELECT 47uF 20% 16V
C103 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C104 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
C105 1-114-322-11 CERAMIC CHIP 0.0047uF 10% 50V
C106 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C107 1-119-772-91 ELECT 47uF 20% 35V
C108 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C109 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C110 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C111 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C112 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C113 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C114 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C115 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C116 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C117 1-124-261-00 ELECT 10uF 20% 50V
C118 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C122 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
DISPLAY
DIGITAL AUDIO
Ver. 1.6
Note: Refer to the SERVICING NOTES “DISPLAY BOARD
DISCRIMINATION” (page 4) for how to distinguish
SUFFIX-12 and SUFFIX-21.
To Next Page
