STR-KM5/KM7
< DIODE >
D120 8-719-053-18 DIODE 1SR154-400TE-25
D121 8-719-053-18 DIODE 1SR154-400TE-25
D122 6-500-848-01 DIODE MC2840-T112-1
D123 6-500-848-01 DIODE MC2840-T112-1
D124 6-502-966-01 DI DZ2J056M0L
< FUSE >
F100 1-523-132-31 FUSE (1A/50V) (KM5: US)
< IC >
IC100 6-701-729-01 IC PT6315
IC101
6-715-134-01 IC MM3404A33URE
IC102 6-600-768-01 IC PNA4823M03S0
< JUMPER RESISTOR >
JR100 1-216-296-11 SHORT CHIP 0
JR101 1-216-296-11 SHORT CHIP 0
JR102 1-216-296-11 SHORT CHIP 0
JR103 1-216-296-11 SHORT CHIP 0
JR104 1-216-296-11 SHORT CHIP 0
JR106 1-216-296-11 SHORT CHIP 0
JR107 1-216-296-11 SHORT CHIP 0
JR108 1-216-296-11 SHORT CHIP 0
JR109 1-216-296-11 SHORT CHIP 0
JR110 1-216-296-11 SHORT CHIP 0
JR111 1-216-296-11 SHORT CHIP 0
JR112 1-216-296-11 SHORT CHIP 0
JR113 1-216-296-11 SHORT CHIP 0
JR114 1-216-296-11 SHORT CHIP 0
JR115 1-216-296-11 SHORT CHIP 0
JR116 1-216-296-11 SHORT CHIP 0
JR117 1-216-296-11 SHORT CHIP 0
JR118 1-216-296-11 SHORT CHIP 0
JR119 1-216-296-11 SHORT CHIP 0
JR120 1-216-296-11 SHORT CHIP 0
JR121 1-216-296-11 SHORT CHIP 0
JR122 1-216-296-11 SHORT CHIP 0
JR123 1-216-296-11 SHORT CHIP 0
JR124 1-216-296-11 SHORT CHIP 0
JR125 1-216-296-11 SHORT CHIP 0
JR127 1-216-296-11 SHORT CHIP 0
JR128 1-216-296-11 SHORT CHIP 0
JR129 1-216-296-11 SHORT CHIP 0
JR130 1-216-296-11 SHORT CHIP 0
JR131 1-216-296-11 SHORT CHIP 0
JR132 1-216-296-11 SHORT CHIP 0
JR133 1-216-296-11 SHORT CHIP 0
JR134 1-216-296-11 SHORT CHIP 0
JR136 1-216-296-11 SHORT CHIP 0
JR137 1-216-296-11 SHORT CHIP 0
JR138 1-216-296-11 SHORT CHIP 0
JR139 1-216-296-11 SHORT CHIP 0
JR140 1-216-296-11 SHORT CHIP 0
JR141 1-216-296-11 SHORT CHIP 0
JR142 1-216-296-11 SHORT CHIP 0
JR143 1-216-296-11 SHORT CHIP 0
JR144 1-216-296-11 SHORT CHIP 0
JR145 1-216-296-11 SHORT CHIP 0
JR146 1-216-296-11 SHORT CHIP 0
JR148 1-216-296-11 SHORT CHIP 0
JR149 1-216-296-11 SHORT CHIP 0
JR151 1-216-296-11 SHORT CHIP 0
JR152 1-216-296-11 SHORT CHIP 0
JR153 1-216-296-11 SHORT CHIP 0
JR154 1-216-296-11 SHORT CHIP 0
JR160 1-216-864-11 SHORT CHIP 0
JR161 1-216-864-11 SHORT CHIP 0
JR162 1-216-864-11 SHORT CHIP 0
JR163 1-216-864-11 SHORT CHIP 0
JR164 1-216-864-11 SHORT CHIP 0
JR165 1-216-864-11 SHORT CHIP 0
JR166 1-216-864-11 SHORT CHIP 0
JR167 1-216-864-11 SHORT CHIP 0
< COIL >
L100 1-481-781-21 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE>
ND100 1-483-416-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q100 6-552-713-01 TR QS5W2TR
Q101 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q102 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q103 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R120 1-216-821-11 METAL CHIP 1K 5% 1/10W
R121 1-216-839-11 METAL CHIP 33K 5% 1/10W
R122 1-216-809-11 METAL CHIP 100 5% 1/10W
R123 1-216-819-11 METAL CHIP 680 5% 1/10W
R124 1-216-819-11 METAL CHIP 680 5% 1/10W
R125 1-216-819-11 METAL CHIP 680 5% 1/10W
R126 1-250-662-11 METAL CHIP 82K 1% 1/10W
R127 1-216-809-11 METAL CHIP 100 5% 1/10W
R128 1-216-809-11 METAL CHIP 100 5% 1/10W
R129 1-216-809-11 METAL CHIP 100 5% 1/10W
R130 1-216-833-11 METAL CHIP 10K 5% 1/10W
R131 1-216-833-11 METAL CHIP 10K 5% 1/10W
R133 1-216-809-11 METAL CHIP 100 5% 1/10W
R135 1-216-797-11 METAL CHIP 10 5% 1/10W
R136 1-216-839-11 METAL CHIP 33K 5% 1/10W
R137 1-216-809-11 METAL CHIP 100 5% 1/10W
< TRANSFORMER >
T100 1-443-645-11 TRANSFORMER, DC CONVERTER
*************************************************************
9 A-1846-040-A HDMI RE PC BOARD, COMPLETE (for SERVICE)
**************************
< CAPACITOR >
C1202 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3510 1-165-492-21 ELECT CHIP 100uF 20% 10V
C3521 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3522 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3529 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3530 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
DISPLAY
HDMI RE PC
Ver. 1.6
Note: Refer to the SERVICING NOTES “DISPLAY BOARD
DISCRIMINATION” (page 4) for how to distinguish
SUFFIX-12 and SUFFIX-21.
