Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
77
STR-KM5/KM7
C213 1-126-964-11 ELECT 10uF 20% 50V
C215 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C217 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C224 1-126-964-11 ELECT 10uF 20% 50V
C225 1-126-964-11 ELECT 10uF 20% 50V
C226 1-126-964-11 ELECT 10uF 20% 50V
C227 1-126-964-11 ELECT 10uF 20% 50V
C228 1-126-964-11 ELECT 10uF 20% 50V
C229 1-126-964-11 ELECT 10uF 20% 50V
C232 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C233 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C235 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C236 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C237 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C238 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C239 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C240 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C241 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C281 1-126-947-11 ELECT 47uF 20% 35V
C692 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
(KM7: AR)
C692 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
(KM7: SP)
C692 1-131-992-91 CERAMIC CHIP 100000PF 35V
(EXCEPT KM5: US/KM7: AR, SP)
C692 1-165-895-91 CERAMIC CHIP 0.1uF 10% 50V
(KM5: US)
C695 1-104-665-11 ELECT 100uF 20% 25V
C901 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C902 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C903 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C904 1-126-936-11 ELECT 3300uF 20% 16V
C905 1-126-960-11 ELECT 1uF 20% 50V
C906 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C911 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C912 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C915 1-126-951-11 ELECT 470uF 20% 35V
C916 1-126-952-11 ELECT 1000uF 20% 35V
< CONNECTOR >
CN271 1-842-650-11 CONNECTOR, BOARD TO BOARD 12P
* CN911 1-564-507-11 PLUG, CONNECTOR 4P
CN912 1-842-639-11 CONNECTOR, BOARD TO BOARD 9P
* CNP901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP902 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
* CNP903 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P
(KM5: E51, EA/KM7: EA)
< DIODE >
D202 6-500-335-01 DIODE MC2838-T112-1
D691 6-502-961-01 DI DA2J10100L
D901 6-502-961-01 DI DA2J10100L
D902 6-500-848-01 DIODE MC2840-T112-1
D903 6-500-848-01 DIODE MC2840-T112-1
D904 6-500-335-01 DIODE MC2838-T112-1
D912 6-503-401-01 DI D3SBA60-7101
< FUSE >
0 F911 1-523-086-11 FUSE (3.15A/250V)
0 F912 1-523-086-11 FUSE (3.15A/250V)
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
FH903 1-533-217-41 HOLDER, FUSE (KM5: E51, EA/KM7: EA)
FH904 1-533-217-41 HOLDER, FUSE (KM5: E51, EA/KM7: EA)
< IC >
IC201 6-717-138-01 IC KIA7805AF-RTF/PW
IC202
6-717-136-01 IC KIA7905F-RTF/PW
IC210 6-704-199-01 IC NJM2595M-TE2
IC220 6-706-767-01 IC NJM2586AM
IC600 6-713-034-01 IC KIA7812API-U/PF
< JACK >
J210 1-815-043-11 JACK, PIN 2P
(SAT/CATV VIDEO IN, MONITOR VIDEO OUT)
J211 1-815-043-11 JACK, PIN 2P (VIDEO VIDEO OUT/IN)
J220 1-816-592-11 JACK, PIN 9P
(COMPONENT VIDEO GAME IN/ BD/DVD IN/
MONITOR OUT)
< JUMPER RESISTOR >
JR200 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q280 6-552-677-01 TR RT1N234M-T111-1
Q697 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q699 8-729-037-13 TRANSISTOR KTA1271Y
Q901 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q902 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R201 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(KM5: TH, E12/KM7: AUS)
R201 1-216-833-11 METAL CHIP 10K 5% 1/10W
(KM7: SP)
R201 1-216-837-11 METAL CHIP 22K 5% 1/10W
(SAF)
R201 1-216-841-11 METAL CHIP 47K 5% 1/10W
(KM5: E51, AR, EA/KM7: AR, EA)
R201 1-216-864-11 SHORT CHIP 0 (KM5: US)
R203 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(AR)
R203 1-216-837-11 METAL CHIP 22K 5% 1/10W
(KM5: E51)
R203 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT KM5: US, E51, AR/KM7: AR)
R204 1-249-401-11 CARBON 47 5% 1/4W
R205 1-249-401-11 CARBON 47 5% 1/4W
R206 1-249-401-11 CARBON 47 5% 1/4W
R207 1-249-401-11 CARBON 47 5% 1/4W
R208 1-249-401-11 CARBON 47 5% 1/4W
R209 1-249-401-11 CARBON 47 5% 1/4W
R211 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R213 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R214 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R215 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R224 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R225 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R226 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R227 1-211-990-11 METAL CHIP 75 0.5% 1/10W
POWER AVIDEO
Ver. 1.5
