Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
78
STR-KM5/KM7
R228 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R229 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R231 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R232 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R233 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R277 1-250-568-11 METAL CHIP 10 1% 1/10W
R278 1-250-568-11 METAL CHIP 10 1% 1/10W
* R279 1-250-572-11 METAL CHIP 15 1% 1/10W
R674 1-216-833-11 METAL CHIP 10K 5% 1/10W
R690 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R694 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R697 1-216-821-11 METAL CHIP 1K 5% 1/10W
R902 1-249-399-11 CARBON 33 5% 1/4W
R903 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R904 1-216-841-11 METAL CHIP 47K 5% 1/10W
R905 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R906 1-216-835-11 METAL CHIP 15K 5% 1/10W
R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
< RELAY >
0 RY901 1-755-541-11 RELAY
< SWITCH >
S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (KM5: E51, EA/KM7: EA)
< TRANSFORMER >
0 T902 1-445-635-21 POWER TRANSFORMER (SUB) (KM5: US)
0 T902 1-697-150-11 POWER TRANSFORMER (SUB)
(KM5: E51, EA/KM7: EA)
0 T902 1-697-152-11 POWER TRANSFORMER (SUB)
(EXCEPT KM5: US, E51, EA/KM7: EA)
< EARTH TERMINAL >
TM200 4-924-264-01 TERMINAL, MOUNT
*************************************************************
POWER KEY BOARD
****************
< CAPACITOR >
C100 1-114-321-11 CERAMIC CHIP 0.0022uF 10% 50V
C101 1-114-321-11 CERAMIC CHIP 0.0022uF 10% 50V
C132 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN107 1-775-377-51 LEAD (WITH CONNECTOR)
< DIODE >
D100 6-503-719-01 DI 1L0352W32B0MIT01 (EXCEPT SAF)
D100 6-503-721-01 DI 1L0353Y22G3MKT01 (SAF)
D102 6-503-719-01 DI 1L0352W32B0MIT01 (EXCEPT SAF)
D102 6-503-721-01 DI 1L0353Y22G3MKT01 (SAF)
D103 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D103 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D105 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D105 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D107 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D107 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
D109 6-503-224-02 DI 1L0352V22F3MIT02 (SAF)
D109 6-503-720-01 DI 1L0353W61B3MKT01 (EXCEPT SAF)
< JUMPER RESISTOR >
JR250 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R100 1-216-837-11 METAL CHIP 22K 5% 1/10W
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-810-11 METAL CHIP 120 5% 1/10W
(EXCEPT SAF)
R102 1-216-812-11 METAL CHIP 180 5% 1/10W
(SAF)
R104 1-216-810-11 METAL CHIP 120 5% 1/10W
(EXCEPT SAF)
R104 1-216-812-11 METAL CHIP 180 5% 1/10W
(SAF)
R105 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R105 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R107 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R107 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R109 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R109 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
R111 1-216-811-11 METAL CHIP 150 5% 1/10W
(EXCEPT SAF)
R111 1-216-813-11 METAL CHIP 220 5% 1/10W
(SAF)
< ROTARY ENCODER>
RV100 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(INPUT SELECTOR)
< SWITCH>
S100 1-762-875-21 SWITCH, TACTILE (\/1)
*************************************************************
SUB RECTIFIER BOARD
*******************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C931 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C932 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C933 1-116-372-11 ELECT (BLOCK) 4700uF 20% 80V
C934 1-116-372-11 ELECT (BLOCK) 4700uF 20% 80V
< CONNECTOR >
* CN931 1-564-509-11 PLUG, CONNECTOR 6P
CN932 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
CNP931 1-785-103-11 PIN, CONNECTOR (3.96mm PITCH) 5P
< DIODE >
D931 6-502-961-01 DI DA2J10100L
D932 8-719-061-07 DIODE D5SBA60-F
Ver. 1.5
POWER KEY
POWER AVIDEO
SUB RECTIFIER
