Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
79
STR-KM5/KM7
< FUSE >
0 F931 1-523-080-11 FUSE (6.3A/250V)
0 F932 1-523-080-11 FUSE (6.3A/250V)
0 F933 1-523-080-11 FUSE (6.3A/250V)
0 F934 1-523-080-11 FUSE (6.3A/250V)
< TRANSISTOR >
Q931 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R931 1-216-841-11 METAL CHIP 47K 5% 1/10W
R932 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R934 1-218-446-11 METAL CHIP 1 5% 1/10W
< RELAY >
RY931 1-755-593-11 RELAY
*************************************************************
SURR BACK AMP BOARD (KM7)
********************
< CAPACITOR >
C401 1-126-964-11 ELECT 10uF 20% 50V (KM7)
C402 1-126-923-91 ELECT 220uF 20% 10V (KM7)
C404 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (KM7)
C408 1-126-947-11 ELECT 47uF 20% 35V (KM7)
C411 1-162-960-11 CERAMIC CHIP 220PF 10% 50V (KM7)
C413 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V (KM7)
C414 1-116-138-11 CERAMIC CHIP 4PF 0.25PF 100V
(KM7)
C415 1-116-137-91 CERAMIC CHIP 12PF 5% 100V
(KM7)
C419 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM7)
C420 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM7)
C422 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V (KM7)
C424 1-116-138-11 CERAMIC CHIP 4PF 0.25PF 100V
(KM7)
C425 1-116-137-91 CERAMIC CHIP 12PF 5% 100V
(KM7)
C429 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM7)
C430 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM7)
C451 1-126-964-11 ELECT 10uF 20% 50V (KM7)
C452 1-126-923-91 ELECT 220uF 20% 10V (KM7)
C454 1-162-927-11 CERAMIC CHIP 100PF 5% 50V (KM7)
C458 1-126-947-11 ELECT 47uF 20% 35V (KM7)
C461 1-162-960-11 CERAMIC CHIP 220PF 10% 50V (KM7)
C463 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V (KM7)
C472 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V (KM7)
< CONNECTOR >
CN405 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P (KM7)
< DIODE >
D401 6-502-961-01 DI DA2J10100L (KM7)
D402 6-502-961-01 DI DA2J10100L (KM7)
D451 6-502-961-01 DI DA2J10100L (KM7)
D452 6-502-961-01 DI DA2J10100L (KM7)
< IC >
IC401 6-715-582-01 IC STK350-630TS-E (KM7)
< JUMPER RESISTOR >
JR413
1-216-296-11 SHORT CHIP 0 (KM7)
< TRANSISTOR >
Q401 8-729-216-22 TRANSISTOR 2SA1162-G (KM7)
Q402 6-552-660-01 TR KTD1028 (KM7)
Q405 6-550-327-01 TR 2SA1514KT146S (KM7)
Q406 6-550-327-01 TR 2SA1514KT146S (KM7)
Q451 8-729-216-22 TRANSISTOR 2SA1162-G (KM7)
Q452 6-552-660-01 TR KTD1028 (KM7)
Q455 6-550-327-01 TR 2SA1514KT146S (KM7)
Q456 6-550-327-01 TR 2SA1514KT146S (KM7)
< RESISTOR >
R401 1-216-821-11 METAL CHIP 1K 5% 1/10W
(KM7)
R402 1-216-843-11 METAL CHIP 68K 5% 1/10W
(KM7)
R403 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
(KM7)
R404 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
(KM7)
R406 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(KM7)
R407 1-216-843-11 METAL CHIP 68K 5% 1/10W
(KM7)
R408 1-216-817-11 METAL CHIP 470 5% 1/10W
(KM7)
R409 1-249-405-11 CARBON 100 5% 1/4W
(KM7)
R410 1-249-405-11 CARBON 100 5% 1/4W
(KM7)
R411 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
(KM7)
R412 1-240-855-91 CARBON 6.2K 5% 1/4W
(KM7)
R413 1-234-182-11 ENCAPSULATED COMPONENT (KM7)
R414 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(KM7)
R415 1-216-835-11 METAL CHIP 15K 5% 1/10W
(KM7)
R416 1-216-843-11 METAL CHIP 68K 5% 1/10W
(KM7)
R417 1-216-841-11 METAL CHIP 47K 5% 1/10W
(KM7)
R418 1-216-841-11 METAL CHIP 47K 5% 1/10W
(KM7)
R419 1-216-845-11 METAL CHIP 100K 5% 1/10W
(KM7)
R420 1-249-393-11 CARBON 10 5% 1/4W
(KM7)
R451 1-216-821-11 METAL CHIP 1K 5% 1/10W
(KM7)
R452 1-216-843-11 METAL CHIP 68K 5% 1/10W
(KM7)
R453 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
(KM7)
R454 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
(KM7)
SURR BACK AMP
Ver. 1.5
SUB RECTIFIER
