Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
80
STR-KM5/KM7
THERMAL
TUNER1
R456 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(KM7)
R457 1-216-843-11 METAL CHIP 68K 5% 1/10W
(KM7)
R458 1-216-817-11 METAL CHIP 470 5% 1/10W
(KM7)
R459 1-249-405-11 CARBON 100 5% 1/4W
(KM7)
R460 1-249-405-11 CARBON 100 5% 1/4W
(KM7)
R461 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
(KM7)
R462 1-240-855-91 CARBON 6.2K 5% 1/4W
(KM7)
R463 1-234-182-11 ENCAPSULATED COMPONENT (KM7)
R464 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(KM7)
R465 1-216-835-11 METAL CHIP 15K 5% 1/10W
(KM7)
R466 1-216-843-11 METAL CHIP 68K 5% 1/10W
(KM7)
R467 1-216-841-11 METAL CHIP 47K 5% 1/10W
(KM7)
R468 1-216-841-11 METAL CHIP 47K 5% 1/10W
(KM7)
R469 1-216-845-11 METAL CHIP 100K 5% 1/10W
(KM7)
R470 1-249-393-11 CARBON 10 5% 1/4W
(KM7)
*************************************************************
THERMAL BOARD
**************
< CAPACITOR >
C250 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< RESISTOR >
R251 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R252 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
< THERMISTOR >
0 TH251 1-804-045-11 THERMISTOR
0 TH252 1-804-045-11 THERMISTOR
*************************************************************
TUNER1AMF BOARD (KM5: US)
TUNER1AMPR BOARD (EXCEPT KM5: US)
*****************
< CAPACITOR >
C101 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C102 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C103 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C105 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C106 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C107 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C108 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C109 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C111 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C112 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
< CONNECTOR >
CN101 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
* CN103 1-506-680-11 PLUG, CONNECTOR (2.5MM) 3P (ANTENNA AM)
CN104 1-780-920-11 TERMINAL (FMAMF)
(ANTENNA 75Ω COAXIAL FM) (KM5: US)
< DIODE >
D101 6-501-579-01 DIODE MC2837
D102 6-501-579-01 DIODE MC2837
D103 6-501-579-01 DIODE MC2837
< FILTER >
FL101 1-236-711-21 FILTER, BAND PASS
< IC >
IC101 6-717-980-01 IC RZ5B801-0001E2 (KM5: US)
IC101 6-717-981-01 IC RZ5B801-0002E2 (EXCEPT KM5: US)
IC102
6-715-134-01 IC MM3404A33URE
< JUMPER RESISTOR >
JR101 1-216-864-1
1 SHORT CHIP 0
JR102 1-216-296-11 SHORT CHIP 0
JR105 1-216-296-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR109 1-216-296-11 SHORT CHIP 0
JR112 1-216-296-11 SHORT CHIP 0
< COIL >
L101 1-457-998-11 COIL, AM ANTENNA
L103 1-414-576-41 INDUCTOR 47nH
L104 1-481-330-21 INDUCTOR 220nH
L105 1-481-523-11 INDUCTOR 4.7uH
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-801-11 METAL CHIP 22 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-801-11 METAL CHIP 22 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-296-11 SHORT CHIP 0
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-767-317-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
A-1851-779-A USB BOARD, COMPLETE (EXCEPT SAF, AR)
********************
< CAPACITOR >
C4101 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
(EXCEPT SAF, AR)
C4109 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4110 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SAF, AR)
C4111 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
Ver. 1.5
SURR BACK AMP
USB
