Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
81
STR-KM5/KM7
C4112 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4113 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
(EXCEPT SAF, AR)
C4114 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
(EXCEPT SAF, AR)
C4115 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4116 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4117 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4118 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4119 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT SAF, AR)
C4120 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT SAF, AR)
C4121 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4162 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
(EXCEPT SAF, AR)
C4163 1-114-330-11 CERAMIC CHIP 2.2uF 10% 16V
(EXCEPT SAF, AR)
C4164 1-114-330-11 CERAMIC CHIP 2.2uF 10% 16V
(EXCEPT SAF, AR)
C4165 1-114-329-11 CERAMIC CHIP 0.47uF 10% 50V
(EXCEPT SAF, AR)
C4166 1-128-390-11 ELECT CHIP 220uF 20% 6.3V
(EXCEPT SAF, AR)
C4167 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SAF, AR)
C4168 1-128-394-11 ELECT CHIP 220uF 20% 10V
(EXCEPT SAF, AR)
C4169 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4182 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SAF, AR)
C4183 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4185 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
C4186 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
(EXCEPT SAF, AR)
C4187 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT SAF, AR)
C4189 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT SAF, AR)
< CONNECTOR >
CN4100 1-817-097-21 PIN, CONNECTOR (1.5MM) (SMD) 13P
(EXCEPT SAF, AR)
CN4101 1-819-866-11 USB CONNECTOR (A) (
) (EXCEPT SAF, AR)
< DIODE >
D4106 8-719-049-09 DIODE 1SS367-T3SONY (EXCEPT SAF, AR)
D4107 6-500-848-01 DIODE MC2840-T112-1 (EXCEPT SAF, AR)
< EARTH TERMINAL >
* ET4100 1-780-408-11 TERMINAL, LUG (EXCEPT SAF, AR)
< FERRITE BEAD >
FB4100 1-469-118-21 FERRITE, EMI (SMD) (1608) (EXCEPT SAF, AR)
FB4102 1-469-324-21 FERRITE, EMI (SMD) (2012) (EXCEPT SAF, AR)
FB4161 1-481-218-21 FERRITE, EMI (SMD) (1608) (EXCEPT SAF, AR)
< IC >
IC4100 6-717-986-11 IC BU94604BKV-ZAE2 (EXCEPT SAF, AR)
IC4101
6-715-164-01 IC TPS2553DBVR (EXCEPT SAF, AR)
IC4102 6-716-739-01 IC BD00GC0WEFJ-SE2 (EXCEPT SAF, AR)
IC4161 6-705-468-01 IC BA33BC0FP-E2 (EXCEPT SAF, AR)
< RESISTOR >
R4111 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4112 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4114 1-218-990-81 SHORT CHIP 0 (EXCEPT SAF, AR)
R4115 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4116 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4117 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4118 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4119 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4120 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4121 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
R4122 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(EXCEPT SAF, AR)
R4123 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4124 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4125 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(EXCEPT SAF, AR)
R4126 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4127 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4129 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
(EXCEPT SAF, AR)
R4130 1-218-989-11 METAL CHIP 1M 5% 1/16W
(EXCEPT SAF, AR)
R4131 1-218-945-11 METAL CHIP 220 5% 1/16W
(EXCEPT SAF, AR)
R4162 1-218-945-11 METAL CHIP 220 5% 1/16W
(EXCEPT SAF, AR)
R4174 1-216-864-11 SHORT CHIP 0 (EXCEPT SAF, AR)
R4175 1-216-864-11 SHORT CHIP 0 (EXCEPT SAF, AR)
R4180 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
(EXCEPT SAF, AR)
R4181 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
(EXCEPT SAF, AR)
R4182 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(EXCEPT SAF, AR)
R4184 1-218-953-11 METAL CHIP 1K 5% 1/16W
(EXCEPT SAF, AR)
R4185 1-218-977-11 METAL CHIP 100K 5% 1/16W
(EXCEPT SAF, AR)
R4186 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4188 1-250-531-11 METAL CHIP 33K 1% 1/16W
(EXCEPT SAF, AR)
USB
Ver. 1.5
