Sony STR-KM77 - Circuit Board Locations

STR-KM22/KM55/KM77
14
• Abbreviation
AR : Argentina model
SAF : South African model
SECTION 5
DIAGRAMS
• Circuit Boards Location
SUB RECTIFIER board (KM55, KM77)
FRONT USB board
(except SAF, AR)
NFC CHAIN board
STANDBY board
SURR BACK AMP board (KM77)
HDMI RE PC board
TUNER1AMPR board
DSP board
MAIN board
LED BAR board
BLUETOOTH MODULE
DISPLAY board
RC-S801/A5 (WW)
POWER KEY board
