For Schematic Diagrams.
Note:
• All capacitors are in μF unless otherwise noted. (p: pF)
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in
Ω
and
1
/
4
W or less unless otherwise
specifi ed.
•
f
: internal component.
•
2
: nonfl ammable resistor.
•
5
: fl usible resistor.
•
C
: panel designation.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
•
A
: B+ Line.
•
B
: B– Line.
• Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
no mark : TUNER
• Voltages are taken with a VOM (Input impedance 10
M
Ω
). Voltage variations may be noted due to normal pro-
duction tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
• Circled numbers refer to waveforms.
• Signal path.
f
: TUNER (FM/AM)
F
: AUDIO (ANALOG)
J
: AUDIO (DIGITAL)
E
: VIDEO
L
: USB
For Printed Wiring Boards.
Note:
•
X
: Parts extracted from the component side.
•
Y
: Parts extracted from the conductor side.
•
f
: Internal component.
•
: Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
• Indication of transistor.
C
B
These are omitted.
E
Q
CEB
These are omitted.
Note: The components identifi ed by mark
0
or dotted
line with mark
0
are critical for safety.
Replace only with part number specifi ed.
Caution:
Pattern face side:
(SIDE B)
Parts face side:
(SIDE A)
Parts on the pattern face side seen
from the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
• Abbreviation
AR : Argentina model
AUS : Australian model
E12 : 220-240 V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
SAF : South African model
SP : Singapore model
TH : Thai model
• Abbreviation
AR : Argentina model
AUS : Australian model
E12 : 220-240 V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
SAF : South African model
SP : Singapore model
TH : Thai model
• Waveforms
– MAIN Board –
1 IC2104 5 (SCK)
500 mV/DIV, 10 ns/DIV
41 ns
1.8 Vp-p
2 IC2104 7 (BCK)
10 V/DIV, 100 ns/DIV
320 ns
31 Vp-p
3 IC2104 8 (LRCK)
20 V/DIV, 10 Ps/DIV
20 Ps
36 Vp-p
4 IC2106 rk (X0)
50 mV/DIV, 100 ns/DIV
250 ns
195 mVp-p
5 IC2106 rl (X1)
200 mV/DIV, 100 ns/DIV
250 ns
480 mVp-p
6 IC2114 3 (MCKIN)
50 mV/DIV, 10 ns/DIV
60 ns
130 mVp-p
7 IC2114 4 (BCKIN)
5 mV/DIV, 25 ns/DIV
60 ns
8 mVp-p
8 IC2114 qd (MCKOUT)
5 V/DIV, 10 ns/DIV
40 ns
14 Vp-p
9 IC2114 qf (BCKOUT)
10 V/DIV, 100 ns/DIV
320 ns
38 Vp-p
q; IC2114 qg (LRCKOUT)
20 V/DIV, 10 Ps/DIV
20 Ps
36 Vp-p
qa IC2114 e; (XMCK)
200 mV/DIV, 2.5 ns/DIV
12.5 ns
720 mVp-p
qs IC2114 ea (XOUT)
5 V/DIV, 10 ns/DIV
40 ns
13 Vp-p
qd IC2114 es (XIN)
500 mV/DIV, 10 ns/DIV
40 ns
1.25 Vp-p
qf IC2119 1 (1CK)
20 V/DIV, 10 Ps/DIV
20 Ps
34 Vp-p
qg IC2119 qd (2CK)
20 V/DIV, 100 Ps/DIV
340 Ps
36 Vp-p
qh IC2700 qf (XIN_PLL)
20 mV/DIV, 25 ns/DIV
60 ns
46 mVp-p
qj IC2700 qg (XOUT_PLL)
100 mV/DIV, 25 ns/DIV
60 ns
400 mVp-p
qk IC2800 rk (PE2/X0)
100 mV/DIV, 10 ns/DIV
20 ns
230 mVp-p
STR-KM22/KM55/KM77
STR-KM22/KM55/KM77
1919
Ver. 1.1
