Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM22/KM55/KM77
72
D2319 8-719-053-18 DIODE 1SR154-400TE-25
D2323 6-503-759-01 DI RB751V40, 115
D2700 1-811-155-11 ELEMENT, ESD PROTECT (EXCEPT SAF, AR)
D2701 1-811-155-11 ELEMENT, ESD PROTECT (EXCEPT SAF, AR)
D2702 6-503-738-01 DI CES521 (EXCEPT SAF, AR)
D2800 6-503-738-01 DI CES521
D2801 6-503-738-01 DI CES521
D2802 6-503-738-01 DI CES521
D2803 6-503-738-01 DI CES521
D2805 6-503-738-01 DI CES521
< FUSE >
0 F910 1-523-085-11 FUSE (2.5A/250V)
0 F911 1-523-085-11 FUSE (2.5A/250V)
< FERRITE BEAD >
FB2031 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2032 1-218-990-81 SHORT CHIP
FB2033 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2034 1-400-862-11 BEAD, FERRITE
FB2035 1-400-862-11 BEAD, FERRITE
FB2036 1-400-862-11 BEAD, FERRITE
FB2037 1-400-862-11 BEAD, FERRITE
FB2038 1-400-862-11 BEAD, FERRITE
FB2039 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2040 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2041 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2042 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2043 1-500-445-21 FERRITE, EMI (SMD) (2012)
* FB2044 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB2045 1-400-973-21 INDUCTOR (EMI FERRITE)
FB2046 1-400-862-11 BEAD, FERRITE
FB2047 1-400-862-11 BEAD, FERRITE
FB2048 1-400-862-11 BEAD, FERRITE
FB2049 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2050 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB2051 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2052 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB2053 1-400-862-11 BEAD, FERRITE
FB2800 1-400-862-11 BEAD, FERRITE
FB2900 1-400-862-11 BEAD, FERRITE (EXCEPT SAF, AR)
FB2901 1-400-862-11 BEAD, FERRITE
FB2902 1-481-218-21 FERRITE, EMI (SMD) (1608) (EXCEPT SAF, AR)
< FUSE HOLDER >
FH953 1-533-217-41 HOLDER, FUSE
FH954 1-533-217-41 HOLDER, FUSE
FH955 1-533-217-41 HOLDER, FUSE
FH956 1-533-217-41 HOLDER, FUSE
< IC >
IC350 6-718-129-01 IC KIA7807AF-RTF/P
IC352 6-718-108-01 IC KIA7907F-RTF/P
IC402 8-759-274-71 IC NJM4565M (TE2)
IC404 6-720-737-01 IC BD34701KS2
IC2010 (Not supplied) IC BD00IC0WHFV-GTR
IC2104 6-712-740-01 IC PCM1681GPWPR
IC2105 6-719-856-01 IC BU4229F-TR
IC2106 A-1989-259-A IC MB9AF156NPMC-G-JNK1E2 (for SERVICE)
IC2107 6-720-177-01 IC BR24T64FJ-WE2
IC2110 6-709-888-01 IC TC7WHU04FK
IC2111 6-600-827-01 IC JSR1124 (OPTICAL IN 2)
IC2112 6-600-827-01 IC JSR1124 (OPTICAL IN 1)
IC2113 6-718-999-01 IC MM1839A50NRE
IC2114 6-717-987-11 IC LC89075WA-H
IC2115 6-718-999-01 IC MM1839A50NRE
IC2117 6-719-856-01 IC BU4229F-TR
IC2118 8-759-680-48 IC TC7WH157FK
IC2119 6-718-383-01 IC TC74VHC393FT (ELK)
IC2700 (Not supplied) IC BU94502AMUV (EXCEPT SAF, AR)
IC2701 6-717-006-01 IC BD00HC5WEFJ-E2 (EXCEPT SAF, AR)
IC2702 6-715-164-01 IC TPS2553DBVR (EXCEPT SAF, AR)
IC2800 A-1990-828-A IC MB9AF156NPMC-G-JNK1E2 (for SERVICE)
IC2803 6-719-856-01 IC BU4229F-TR
IC2903 6-718-324-01 IC MFI337S3959
< JACK >
J403 1-774-411-11 JACK, PIN 6P
(AUDIO IN 1 L/R / AUDIO IN 2 L/R / AUDIO TV IN L/R)
J2301 1-784-431-11 JACK, PIN 1P (COAXIAL IN)
< JUMPER RESISTOR >
JW003 1-211-950-11 SHORT CHIP 0 (KM22)
JW010 1-211-950-11 SHORT CHIP 0 (KM22)
< COIL >
L550 1-420-872-52 COIL, AIR-CORE (KM55, KM77)
L700 1-420-872-52 COIL, AIR-CORE
L750 1-420-872-52 COIL, AIR-CORE
L800 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q320 6-550-327-01 TR 2SA1514KT146S
Q321 6-553-266-01 TR 2PD601ART
Q323 6-550-327-01 TR 2SA1514KT146S
Q324 6-553-266-01 TR 2PD601ART
Q325 8-729-271-31 TRANSISTOR 2SC2713G-TE85L
Q350 6-553-266-01 TR 2PD601ART
Q355 6-553-266-01 TR 2PD601ART
Q360 6-553-266-01 TR 2PD601ART
Q365 6-553-266-01 TR 2PD601ART
Q552 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
(KM55, KM77)
Q553 8-729-023-22 TRANSISTOR 2SD2114KT146 (KM55, KM77)
Q554 6-550-327-01 TR 2SA1514KT146S (KM55, KM77)
Q555 6-550-327-01 TR 2SA1514KT146S (KM55, KM77)
Q570 6-550-032-01 TRANSISTOR HN4A06J-GRBL (TE85R)
(KM55, KM77)
Q572 6-553-334-01 TR KTA1024-Y (KM55, KM77)
Q574 6-553-335-01 TR KTC3206-Y (KM55, KM77)
Q575 6-553-335-01 TR KTC3206-Y (KM55, KM77)
Q602 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q603 8-729-023-22 TRANSISTOR 2SD2114KT146
Q604 6-550-327-01 TR 2SA1514KT146S
Q605 6-550-327-01 TR 2SA1514KT146S
Q620 6-550-032-01 TRANSISTOR HN4A06J-GRBL (TE85R)
Q622 6-553-334-01 TR KTA1024-Y
Q624 6-553-335-01 TR KTC3206-Y
Q625 6-553-335-01 TR KTC3206-Y
Q652 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q653 8-729-023-22 TRANSISTOR 2SD2114KT146
Q654 6-550-327-01 TR 2SA1514KT146S
MAIN
Note: IC2010 and IC2700 on the MAIN board cannot exchange
with single. When these parts on the MAIN board are dam-
aged, exchange the entire mounted board.
Ver. 1.1
