Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM22/KM55/KM77
8787
R474 1-216-813-11 METAL CHIP 220 5% 1/10W
(KM77)
R475 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(KM77)
R476 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(KM77)
R477 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(KM77)
R478 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(KM77)
R479 1-216-817-11 METAL CHIP 470 5% 1/10W
(KM77)
R480 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(KM77)
R481 1-216-814-11 METAL CHIP 270 5% 1/10W
(KM77)
R482 1-249-377-11 CARBON 0.47 5% 1/4W
(KM77)
*************************************************************
TUNER1AMPR BOARD
******************
< CAPACITOR >
C101 1-100-155-91 CERAMIC CHIP 470PF 5% 100V
C102 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C103 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C105 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C106 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C107 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C108 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C109 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C111 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C112 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
< CONNECTOR >
CN101 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
* CN103 1-506-680-11 PLUG, CONNECTOR (2.5MM) 3P (ANTENNA AM)
< DIODE >
D101 6-501-579-01 DIODE MC2837
D102 6-501-579-01 DIODE MC2837
D103 6-501-579-01 DIODE MC2837
<FILTER >
FL101 1-236-711-21 FILTER, BAND PASS
< IC >
IC101 6-717-981-01 IC RZ5B801-0002E2
IC102 6-715-134-01 IC MM3404A33URE
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-296-11 SHORT CHIP 0
JR105 1-216-296-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR112 1-216-296-11 SHORT CHIP 0
< COIL >
L101 1-457-998-11 COIL, AM ANTENNA
L103 1-414-576-41 INDUCTOR 47nH
L104 1-481-330-21 INDUCTOR 220nH
L105 1-481-523-11 INDUCTOR 4.7uH
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-801-11 METAL CHIP 22 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-801-11 METAL CHIP 22 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-296-11 SHORT CHIP 0
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-767-317-11 VIBRATOR, CRYSTAL (32.768KHz)
*************************************************************
MISCELLANEOUS
**************
3 1-828-361-21 WIRE (FLAT TYPE) (19 CORE)
52 1-828-404-61 WIRE (FLAT TYPE) (27 CORE)
53 1-828-310-21 WIRE (FLAT TYPE) (9 CORE)
55 1-828-171-61 WIRE (FLAT TYPE) (8 CORE)
56 8-989-470-05 RC-S801/A5 (WW)
58 1-828-204-61 WIRE (FLAT TYPE) (14 CORE)
59 1-490-558-92 BLUETOOTH MODULE
104 1-828-311-21 WIRE (FLAT TYPE) (9 CORE)
105 A-1846-561-A TUNER1AMPR ASSY
0 107 1-777-071-83 CORD, POWER (E51, SAF, SP)
0 107 1-835-068-21 CORD, POWER (AUS)
0 107 1-837-312-11 CORD, POWER-SUPPLY (AR)
0 107 1-839-012-11 CORD, POWER-SUPPLY (E12)
0 107 1-839-940-21 POWER-SUPPLY CORD (TH)
0 107 1-839-999-21 POWER-SUPPLY CORD (EA)
0 F901 1-532-504-33 FUSE (T4AL/250V)
0 F902 1-532-506-33 FUSE (T6.3AL/250V) (E51, EA)
0 F914 1-533-949-33 FUSE (T8AL/250V)
0 F915 1-533-949-33 FUSE (T8AL/250V)
0 M1 1-855-006-11 FAN, DC (KM55, KM77)
0 M2 1-787-955-21 DC FAN (KM55, KM77)
Q403 6-702-390-01 TRANSISTOR MN2488-OPY-MK (KM77)
Q404 6-702-391-01 TRANSISTOR MP1620-OPY-MK (KM77)
Q453 6-702-390-01 TRANSISTOR MN2488-OPY-MK (KM77)
Q454 6-702-391-01 TRANSISTOR MP1620-OPY-MK (KM77)
Q550 6-702-390-01 TRANSISTOR MN2488-OPY-MK (KM55, KM77)
Q551 6-702-391-01 TRANSISTOR MP1620-OPY-MK (KM55, KM77)
Q600 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q601 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q650 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q651 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q700 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q701 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q750 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q751 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q800 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q801 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q850 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q851 6-702-391-01 TRANSISTOR MP1620-OPY-MK
SURR BACK AMP TUNER1AMPR
Note: If wire (fl at type) is replaced, install it after bending it in the
same form as that before replacement.
Ver. 1.1
