STR-KS2000
SECTION 8
ELECTRICAL PARTS LIST
DCAC (2000) BOARD
****************
< CAPACITOR >
C2500 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2502 1-124-261-00 ELECT 10uF 20% 50V
C2503 1-124-261-00 ELECT 10uF 20% 50V
C2504 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2505 1-124-261-00 ELECT 10uF 20% 50V
C2506 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2513 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2514 1-119-772-11 ELECT 47uF 20% 35V
C2515 1-124-261-00 ELECT 10uF 20% 50V
C2516 1-124-261-00 ELECT 10uF 20% 50V
C2517 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2518 1-104-957-11 ELECT 47uF 20% 25V
C2519 1-126-160-11 ELECT 1uF 20% 50V
C2520 1-124-261-00 ELECT 10uF 20% 50V
C2521 1-124-261-00 ELECT 10uF 20% 50V
C2522 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2523 1-104-957-11 ELECT 47uF 20% 25V
C2524 1-119-772-11 ELECT 47uF 20% 35V
C2525 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2526 1-124-261-00 ELECT 10uF 20% 50V
C2528 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2529 1-119-772-11 ELECT 47uF 20% 35V
C2530 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< DIODE >
D2500 8-719-404-50 DIODE MA111-TX
< GROUND TERMINAL >
EB2500 1-537-738-21 TERMINAL, GROUND
< FERRITE BEAD >
FB2500 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC2501 8-759-825-56 IC NJM2173AV (TE2)
IC2502 6-705-468-01 IC BA33BC0FP-E2
<
JACK >
J2500 1-820-056-11 SMALL
TYPE JACK (AUTO CAL MIC)
< TRANSISTOR >
Q2500 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
< RESISTOR >
R2501 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2503 1-216-849-11 METAL CHIP 220K 5% 1/10W
R2504 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2506 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2507 1-216-843-11 METAL CHIP 68K 5% 1/10W
R2508 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2513 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2514 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2518 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2519 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
DISPLAY BOARD
**************
4-246-476-01 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C700 1-126-795-11 ELECT 10uF 20% 50V
C701 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C702 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C703 1-126-795-11 ELECT 10uF 20% 50V
C704 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C705 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C706 1-126-795-11 ELECT 10uF 20% 50V
C707 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C708 1-126-795-11 ELECT 10uF 20% 50V
C709 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C711 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C750 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C751 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C752 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C753 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C754 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C755 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
