Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KS2000
6767
< DIODE >
D1700 8-719-404-50 DIODE MA111-TX
< IC >
IC1700 6-600-466-01 IC TORX147L (SONY) (DIGITAL OPT IN SAT)
IC1701 6-600-466-01 IC TORX147L (SONY)
(DIGITAL OPT IN VIDEO 1)
IC1711 8-759-242-70 IC TC7WU04F
< JACK >
J1700 1-793-446-21 JACK, PIN 1P (DIGITAL COAX IN DVD)
< RESISTOR >
R1701 1-218-285-11 METAL CHIP 75 5% 1/10W
R1702 1-216-817-11 METAL CHIP 470 5% 1/10W
R1703 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1704 1-216-853-11 METAL CHIP 470K 5% 1/10W
R1705 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
IR BOARD
********
< CAPACITOR >
C710 1-124-589-11 ELECT 47uF 20% 16V
C765 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C768 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
CNP700 1-766-739-11 CONNECTOR, BOARD TO BOARD 8P
CNS701 1-784-778-11 CONNECTOR, FFC 17P
< IC >
IC701 6-600-349-31 IC NJL24H400A
< RESISTOR >
R752 1-216-809-11 METAL
CHIP 100 5% 1/10W
0 R753 1-249-393-11 CARBON 10 5% 1/4W F
R754 1-216-821-11 METAL CHIP 1K 5% 1/10W
R755 1-216-821-11 METAL CHIP 1K 5% 1/10W
R756 1-216-821-11 METAL CHIP 1K 5% 1/10W
< ROTARY ENCODER >
RV700 1-418-725-51 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S701 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING –)
S702 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING +)
S703 1-771-349-21 SWITCH, KEYBOARD (SOUND FIELD –)
S704 1-771-349-21 SWITCH, KEYBOARD (SOUND FIELD +)
S705 1-771-349-21 SWITCH, KEYBOARD (INPUT SELECTOR)
S706 1-771-349-21 SWITCH, KEYBOARD (MUTING)
************************************************************
A-1259-822-A MAIN BOARD, COMPLETE (US) (for HT-SS2000)
A-1259-835-A MAIN BOARD, COMPLETE (AEP, UK)
A-1319-421-A MAIN BOARD, COMPLETE
(US, CND) (for HT-SF2000)
********************
< CAPACITOR >
C1006 1-126-965-11 ELECT 22uF 20% 50V
C1007 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1008 1-165-722-11 ELECT 100uF 20% 10V
C1010 1-126-964-11 ELECT 10uF 20% 50V
C1011 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1013 1-112-119-11 ELECT 470uF 20% 10V
C1014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1017 1-117-370-11 CERAMIC CHIP 10uF 10V
C1018 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1023 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1029 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1030 1-117-370-11 CERAMIC CHIP 10uF 10V
C1033 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1036 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1037 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1038 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1039 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1043 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1044 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C1048 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C1049 1-117-370-11 CERAMIC CHIP 10uF 10V
C1050 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1051 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1053 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1054 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1055 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1056 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1057 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1058 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1059 1-117-370-11 CERAMIC CHIP 10uF 10V
C1060 1-126-933-11 ELECT 100uF 20% 16V
C1061 1-126-933-11 ELECT 100uF 20% 16V
C1062 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1063 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1064 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1065 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1066 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1067 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1068 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
IO IR MAIN
