17
STR-KS2000
3. ELECTRICAL PARTS LIST
A-1259-822-A MAIN BOARD, COMPLETE (US) (for HT-SS2000)
A-1259-835-A MAIN BOARD, COMPLETE (AEP, UK)
A-1319-421-A MAIN BOARD, COMPLETE
(US, CND) (for HT-SF2000)
********************
< CAPACITOR >
C1010 1-126-964-11 ELECT 10uF 20% 50V
C1011 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1013 1-112-119-11 ELECT 470uF 20% 10V
C1014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1017 1-117-370-11 CERAMIC CHIP 10uF 10V
C1018 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1023 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1029 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1030 1-117-370-11 CERAMIC CHIP 10uF 10V
C1033 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1036 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1037 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1038 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1039 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1043 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1044 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C1048 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C1049 1-117-370-11 CERAMIC CHIP 10uF 10V
C1050 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1051 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1053 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1054 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1055 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1056 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1057 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1058 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1059 1-117-370-11 CERAMIC CHIP 10uF 10V
C1060 1-126-933-11 ELECT 100uF 20% 16V
C1061 1-126-933-11 ELECT 100uF 20% 16V
C1062 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1063 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1064 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1065 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1066 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1067 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1068 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1069 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1070 1-112-119-11 ELECT 470uF 20% 10V
C1072 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1073 1-112-119-11 ELECT 470uF 20% 10V
C1074 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C1075 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1076 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1077 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1078 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1079 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1080 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1081 1-126-960-11 ELECT 1uF 20% 50V
C1082 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1083 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C1084 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1088 1-112-100-11 ELECT 10uF 20% 50V
C1092 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1094 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1095 1-126-933-11 ELECT 100uF 20% 16V
C1096 1-117-370-11 CERAMIC CHIP 10uF 10V
C1097 1-117-370-11 CERAMIC CHIP 10uF 10V
C1101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1102 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1104 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1107 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1108 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1118 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
