Multi Channel Surround Setup
-r
0
0
5'
c
"o
¢D
e,*
5'
c
"o
¢D
"o
¢D
¢D
e,*
¢D
3
• Sub woofer selection (SUB WOOFER)
Initial setting : YES
• If you connect a sub woot_r, select "YES".
• If you do not connect a sub woofel; select "NO". This
activates the bass rediiectkm circuitry and outpt_ts the
LFE signals fi'om other speakers.
• In order to take full advantage of tile Dolby Digital
(AC 3) [)ass redirection circuitry, we recommend setting
tile sub woofer's cut off fl'equency as high as possible.
• Front speaker distance (FRONT)
Initial setting : 16 t_et (5.0 meter)
Set tile distance fl'om your listening position to the fl'ont
(left or right) speaker (_ on page 18).
• Front speaker distance can be set in 1 foot (0.1 meter)
steps fl'om 3 to 40 fleet (1.0 to 12.0 meters).
• If both speakers are not placed an equal distance flom
your listening position, set tile distance to tile closest
speaker.
• Center speaker distance (CENTER)
Initial setting : 16 t_et (5.0 meter)
Set tile distance fl'om your listening position to the center
speakm_
• Center speaker distance can be set in 1 fioot (0.1 meter)
steps fl'om a distance equal to the front speaker distance
(_ on page 18) to a distance 5 feet (1.5 meters) closer to
your listening position (O on page 18).
• Do not place the center speaker farther away from your
listening position than the fl'ont speakers.
• Rear L/R speaker distance (REAR L/R)
Initial setting : 11 fleet (3.5 meter)
Set tile distance fl'om your listening position to the _ar
(left or right) speaker.
• Rear L/R speaker distance can be set in 1 foot (0.1
ineter) steps froin a distance equal to the fl'ont speaker
distance (_ on page 18) to a distance 15 feet (4.5
ineters) closer to your listening position (_ on page 18).
• Do not place the rear L/R speakers farther away fl'oin
your listening position than the front speakers.
• If both speakers are not placed an equal distance fl'om
your listening position, set tile distance to tile closest
speaker.
• Rear center speaker distance (REAR CTR)
Initial setting : 11%et (3.5 meter)
Set the distance from your listening position to the rear
center speaker.
• Rear center speaker distance can be set in 1 foot (0.1
meter) steps fi'oii1 a distance equal to tile fl'ont speaker
distance (_ on page 18) to a distance 15 feet (4.5
meters) closer to your listening position (_ on page 18).
• Do not place tile rear center speaker farther away from
your listening position than tile front speakers.
"_" About speaker distances
This trait allows you to input the speaker position in terms of
distance. However; it is not possible to set the center speaker
further than the fl'ont speakers. Also, the center speaker cannot he
set more that 5 feet (1.5 meters) closer than the flont speakers.
Likewise, the rear L/R speakers can not he set farther away from
the listening position than the fl'ont speakers. And they can he no
more than 15 feet (4.5 meters) closei:
This is because incorrect speaker placement is not conducive to
the enjoyment of surround sound.
Please note that, setting the speaker distance closer than the
actual location of the speakers will cause a delay in the output of
the sotmd fl'om that speaker: In other words, the speaker will
sound like it is farther away.
For example, setting the center speaker distance 36 feet (1 -2 m)
closer than the actual speaker position will create a fairly realistic
sensation of being "inside" the screen. If you cannot obtain a
satisfactory surrotmd eftbct because the rear L/R speakers are too
close, setting the rear L/R speaker distance closer (shorter) than
the actual distance will create a larger sotmdstage.
Adjusting these parameter while listening to the sound often
restflts in nmch hetter surrotmd sotmd. Give it a try!
20
