Sony TA-FB930R - General Section Overview; Front Panel Control Identification

3
Front Panel Descriptions
SECTION 1
GENERAL
1 PROTECTION indicator
2 U (Power) button
3 Remote sensor
4 EON LINK indicator
5 TAPE 1/DAT indicator
6 TAPE 2/MD indicator
7 AUX indicator
8 CD indicator
9 TUNER indicator
10 PHONO indicator
11 INPUT SELECTOR knob
12 VOLUME knob
13 SOURCE DIRECT button and indicator
14 TAPE MONITOR knob
15 SUBSONIC button
16 LOUDNESS button
17 BALANCE knob
18 TREBLE knob
19 BASS knob
20 SPEAKERS knob
21 PHONE jack
22 EON LINK button
9
78
2
3
4
65110
11
13
12
14
15
16
17
1819
20
21
This section is extracted from
instruction manual.
22
