21
TA-S3
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC INPUT AC OUTPUT
FRONT AMP
1-680-752-11 AC INPUT BOARD
***************
**************************************************************
1-680-753-11 AC OUTPUT BOARD
****************
1-533-217-41 HOLDER, FUSE
< CONNECTOR >
CN913 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN914 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN915 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< FUSE >
0 F931 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V)
0 F934 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V)
0 F935 1-533-469-11 FUSE, GLASS TUBE (DIA. 5) (T2.5AL/250V)
0 F936 1-533-469-11 FUSE, GLASS TUBE (DIA. 5) (T2.5AL/250V)
0 F937 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) (T4AL/250V)
**************************************************************
A-4476-205-A FRONT AMP BOARD, COMPLETE
**************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C801 1-126-963-11 ELECT 4.7uF 20% 50V
C802 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-104-664-11 ELECT 47uF 20% 10V
C806 1-136-495-11 FILM 0.068uF 5% 50V
C807 1-136-495-11 FILM 0.068uF 5% 50V
C808 1-136-165-00 FILM 0.1uF 5% 50V
C809 1-136-165-00 FILM 0.1uF 5% 50V
C811 1-162-306-11 CERAMIC 0.01uF 30% 16V
C812 1-162-306-11 CERAMIC 0.01uF 30% 16V
C821 1-107-721-11 ELECT 4.7uF 20% 100V
C837 1-126-963-11 ELECT 4.7uF 20% 50V
C851 1-126-963-11 ELECT 4.7uF 20% 50V
C852 1-162-286-31 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-104-664-11 ELECT 47uF 20% 10V
C856 1-136-495-11 FILM 0.068uF 5% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
C857 1-136-495-11 FILM 0.068uF 5% 50V
C858 1-136-165-00 FILM 0.1uF 5% 50V
C859 1-136-165-00 FILM 0.1uF 5% 50V
C861 1-162-306-11 CERAMIC 0.01uF 30% 16V
C862 1-162-306-11 CERAMIC 0.01uF 30% 16V
C871 1-107-721-11 ELECT 4.7uF 20% 100V
C872 1-126-959-11 ELECT 0.47uF 20% 50V
C891 1-104-665-11 ELECT 100uF 20% 10V
C892 1-126-961-11 ELECT 2.2uF 20% 50V
C893 1-104-665-11 ELECT 100uF 20% 10V
C911 1-130-777-00 MYLAR 0.1uF 5% 100V
C912 1-130-777-00 MYLAR 0.1uF 5% 100V
C914 1-115-871-11 ELECT 1uF 20% 50V
C915 1-162-282-31 CERAMIC 100PF 10% 50V
C916 1-162-282-31 CERAMIC 100PF 10% 50V
C917 1-162-282-31 CERAMIC 100PF 10% 50V
C918 1-164-159-11 CERAMIC 0.1uF 50V
C919 1-126-964-11 ELECT 10uF 20% 50V
C920 1-164-159-11 CERAMIC 0.1uF 50V
C924 1-162-294-31 CERAMIC 0.001uF 10% 50V
C925 1-126-795-11 ELECT 10uF 20% 50V
C926 1-126-382-11 ELECT 100uF 20% 16V
C927 1-104-665-11 ELECT 100uF 20% 10V
C941 1-164-159-11 CERAMIC 0.1uF 50V
C951 1-135-516-11 ELECT 3300uF 20% 63V
C952 1-135-516-11 ELECT 3300uF 20% 63V
C961 1-128-563-11 ELECT 100uF 20% 100V
C962 1-128-563-11 ELECT 100uF 20% 100V
C963 1-104-665-11 ELECT 100uF 20% 10V
C964 1-119-943-11 ELECT 47uF 20% 50V
C987 1-164-159-11 CERAMIC 0.1uF 50V
C990 1-164-159-11 CERAMIC 0.1uF 50V
C991 1-126-940-11 ELECT 330uF 20% 25V
C992 1-113-342-11 CERAMIC 0.1uF 50V
C993 1-126-935-11 ELECT 470uF 20% 16V
C994 1-126-176-11 ELECT 220uF 20% 10V
C1100 1-164-159-11 CERAMIC 0.1uF 50V
C1101 1-164-159-11 CERAMIC 0.1uF 50V
C1102 1-164-159-11 CERAMIC 0.1uF 50V
C1103 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN104 1-784-784-11 CONNECTOR, FFC 23P
