Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
22
TA-S3
CN105 1-564-506-11 PLUG, CONNECTOR 3P
CN106 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN107 1-794-498-21 SOCKET, CONNECTOR 20P
(SYSTEM CONTROL 1 FROM ST-S3)
< DIODE >
D801 8-719-911-19 DIODE 1SS133T-72
D802 8-719-911-19 DIODE 1SS133T-72
D821 8-719-911-19 DIODE 1SS133T-72
D831 8-719-911-19 DIODE 1SS133T-72
D851 8-719-911-19 DIODE 1SS133T-72
D871 8-719-911-19 DIODE 1SS133T-72
D881 8-719-911-19 DIODE 1SS133T-72
D911 8-719-510-68 DIODE D5SBA204101
D923 8-719-024-99 DIODE 11ES2-NTA2B
D924 8-719-024-99 DIODE 11ES2-NTA2B
D925 8-719-911-19 DIODE 1SS133T-72
D926 8-719-911-19 DIODE 1SS133T-72
D963 8-719-911-19 DIODE 1SS133T-72
D970 8-719-024-99 DIODE 11ES2-NTA2B
D971 8-719-024-99 DIODE 11ES2-NTA2B
D972 8-719-024-99 DIODE 11ES2-NTA2B
D973 8-719-024-99 DIODE 11ES2-NTA2B
D974 8-719-024-99 DIODE 11ES2-NTA2B
D975 8-719-024-99 DIODE 11ES2-NTA2B
D980 8-719-024-99 DIODE 11ES2-NTA2B
D981 8-719-024-99 DIODE 11ES2-NTA2B
D990 8-719-024-99 DIODE 11ES2-NTA2B
D991 8-719-024-99 DIODE 11ES2-NTA2B
D992 8-719-024-99 DIODE 11ES2-NTA2B
D993 8-719-024-99 DIODE 11ES2-NTA2B
D994 8-719-024-99 DIODE 11ES2-NTA2B
D995 8-719-024-99 DIODE 11ES2-NTA2B
D996 8-719-024-99 DIODE 11ES2-NTA2B
D997 8-719-024-99 DIODE 11ES2-NTA2B
< GROUND TERMINAL >
EPT901 1-537-770-21 TERMINAL BOARD, GROUND
EPT902 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC310 6-800-467-01 IC PT8300-S
IC801 8-749-016-94 IC STK402-090S
IC923 8-759-595-88 IC NJM78L12A-T3
IC924 8-759-708-05 IC NJM78L05A-T3
< COIL >
L811 1-420-872-00 COIL, AIR-CORE
L861 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q801 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q821 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q822 8-729-900-63 TRANSISTOR BN1F4M-TP
Q841 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q842 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q851 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q871 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q881 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q883 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q891 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q892 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q893 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q894 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q895 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q896 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q897 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q902 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q903 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q904 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q961 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q962 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q963 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-249-410-11 CARBON 270 5% 1/4W
R804 1-249-438-11 CARBON 56K 5% 1/4W
0 R805 1-234-499-21 ENCAPSULATED COMPONENT 0.22 5W
R806 1-249-417-11 CARBON 1K 5% 1/4W
R807 1-249-431-11 CARBON 15K 5% 1/4W
R808 1-249-441-11 CARBON 100K 5% 1/4W
R809 1-260-076-11 CARBON 10 5% 1/2W
R812 1-260-072-11 CARBON 4.7 5% 1/2W
R814 1-249-437-11 CARBON 47K 5% 1/4W
R815 1-249-437-11 CARBON 47K 5% 1/4W
0 R821 1-216-455-11 METAL OXIDE 560 5% 2W F
R825 1-249-402-11 CARBON 56 5% 1/4W
R826 1-249-417-11 CARBON 1K 5% 1/4W
R827 1-249-433-11 CARBON 22K 5% 1/4W
R841 1-249-441-11 CARBON 100K 5% 1/4W
R842 1-249-439-11 CARBON 68K 5% 1/4W
R843 1-249-439-11 CARBON 68K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-249-410-11 CARBON 270 5% 1/4W
R854 1-249-438-11 CARBON 56K 5% 1/4W
0 R855 1-234-499-21 ENCAPSULATED COMPONENT 0.22 5W
R856 1-249-417-11 CARBON 1K 5% 1/4W
R857 1-249-431-11 CARBON 15K 5% 1/4W
R858 1-249-441-11 CARBON 100K 5% 1/4W
R859 1-260-076-11 CARBON 10 5% 1/2W
R862 1-260-072-11 CARBON 4.7 5% 1/2W
0 R871 1-216-455-11 METAL OXIDE 560 5% 2W F
R875 1-249-402-11 CARBON 56 5% 1/4W
R876 1-249-417-11 CARBON 1K 5% 1/4W
R877 1-249-433-11 CARBON 22K 5% 1/4W
R878 1-249-425-11 CARBON 4.7K 5% 1/4W
R879 1-249-441-11 CARBON 100K 5% 1/4W
R880 1-247-903-00 CARBON 1M 5% 1/4W
0 R881 1-216-456-00 METAL OXIDE 820 5% 2W F
R883 1-249-437-11 CARBON 47K 5% 1/4W
R885 1-249-429-11 CARBON 10K 5% 1/4W
R887 1-249-441-11 CARBON 100K 5% 1/4W
FRONT AMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
