Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
23
TA-S3
R889 1-249-429-11 CARBON 10K 5% 1/4W
R891 1-249-438-11 CARBON 56K 5% 1/4W
R892 1-249-439-11 CARBON 68K 5% 1/4W
R894 1-249-429-11 CARBON 10K 5% 1/4W
R895 1-249-429-11 CARBON 10K 5% 1/4W
R896 1-249-435-11 CARBON 33K 5% 1/4W
R897 1-249-433-11 CARBON 22K 5% 1/4W
R898 1-249-425-11 CARBON 4.7K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-441-11 CARBON 100K 5% 1/4W
R905 1-249-421-11 CARBON 2.2K 5% 1/4W
R906 1-249-417-11 CARBON 1K 5% 1/4W
R907 1-249-421-11 CARBON 2.2K 5% 1/4W
R908 1-249-421-11 CARBON 2.2K 5% 1/4W
R910 1-247-807-31 CARBON 100 5% 1/4W
R911 1-247-807-31 CARBON 100 5% 1/4W
R912 1-247-807-31 CARBON 100 5% 1/4W
R913 1-249-437-11 CARBON 47K 5% 1/4W
R914 1-247-807-31 CARBON 100 5% 1/4W
R915 1-249-437-11 CARBON 47K 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-249-411-11 CARBON 330 5% 1/4W
R918 1-249-411-11 CARBON 330 5% 1/4W
R919 1-249-411-11 CARBON 330 5% 1/4W
R920 1-249-411-11 CARBON 330 5% 1/4W
R921 1-249-411-11 CARBON 330 5% 1/4W
R923 1-249-417-11 CARBON 1K 5% 1/4W
R924 1-249-437-11 CARBON 47K 5% 1/4W
R925 1-249-437-11 CARBON 47K 5% 1/4W
R926 1-249-429-11 CARBON 10K 5% 1/4W
R927 1-249-437-11 CARBON 47K 5% 1/4W
R951 1-249-441-11 CARBON 100K 5% 1/4W
R952 1-249-441-11 CARBON 100K 5% 1/4W
0 R963 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R964 1-212-881-11 FUSIBLE 100 5% 1/4W F
R965 1-249-431-11 CARBON 15K 5% 1/4W
R966 1-249-435-11 CARBON 33K 5% 1/4W
R967 1-249-429-11 CARBON 10K 5% 1/4W
0 R968 1-202-972-61 FUSIBLE 1 5% 1/4W F
R969 1-249-433-11 CARBON 22K 5% 1/4W
R970 1-249-441-11 CARBON 100K 5% 1/4W
R971 1-249-421-11 CARBON 2.2K 5% 1/4W
R972 1-249-433-11 CARBON 22K 5% 1/4W
R973 1-249-421-11 CARBON 2.2K 5% 1/4W
R974 1-249-429-11 CARBON 10K 5% 1/4W
R991 1-249-417-11 CARBON 1K 5% 1/4W
R992 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
RY881 1-515-920-11 RELAY
< TERMINAL >
TM101 1-694-677-12 TERMINAL BOARD (4P)
(FRONT SPEAKER IMPEDANCE USE 6-16Ω)
**************************************************************
A-4476-220-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-162-306-11 CERAMIC 0.01uF 30% 16V
C703 1-162-306-11 CERAMIC 0.01uF 30% 16V
C704 1-162-306-11 CERAMIC 0.01uF 30% 16V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
C706 1-162-306-11 CERAMIC 0.01uF 30% 16V
C710 1-162-294-31 CERAMIC 0.001uF 10% 50V
C711 1-162-306-11 CERAMIC 0.01uF 30% 16V
C712 1-162-294-31 CERAMIC 0.001uF 10% 50V
C781 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN700 1-784-745-11 CONNECTOR, FFC 23P
< DIODE >
D701 8-719-058-04 LED SEL5223S-TP15 (I/1)
D702 8-719-057-97 LED SEL5923A-TP15 (SUR)
D703 8-719-057-97 LED SEL5923A-TP15 (EQ)
D704 8-719-057-97 LED SEL5923A-TP15 (MUSIC MODE, A)
D705 8-719-057-97 LED SEL5923A-TP15 (MOVIE MODE, B)
D706 8-719-057-97 LED SEL5923A-TP15 (2CH/MULTI, C)
D781 8-719-084-07 LED SEL5E20CTP15
(MULTI CHANNEL DECODING)
< JACK >
J703 1-691-293-21 JACK (PHONES)
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR BA1A4M-TP
Q702 8-729-900-63 TRANSISTOR BN1F4M-TP
< RESISTOR >
R707 1-249-411-11 CARBON 330 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-249-410-11 CARBON 270 5% 1/4W
R710 1-249-413-11 CARBON 470 5% 1/4W
R711 1-249-414-11 CARBON 560 5% 1/4W
R712 1-249-416-11 CARBON 820 5% 1/4W
R713 1-249-417-11 CARBON 1K 5% 1/4W
R714 1-249-418-11 CARBON 1.2K 5% 1/4W
R715 1-249-419-11 CARBON 1.5K 5% 1/4W
R716 1-249-421-11 CARBON 2.2K 5% 1/4W
R717 1-249-422-11 CARBON 2.7K 5% 1/4W
R718 1-249-424-11 CARBON 3.9K 5% 1/4W
R719 1-249-426-11 CARBON 5.6K 5% 1/4W
R720 1-249-428-11 CARBON 8.2K 5% 1/4W
R721 1-249-431-11 CARBON 15K 5% 1/4W
< SWITCH >
S701 1-473-534-11 ENCODER, ROTARY (FUNCTION)
S702 1-473-534-11 ENCODER, ROTARY (FILE SELECT)
S703 1-473-392-11 ENCODER, ROTARY (VOLUME)
S705 1-771-410-21 SWITCH, TACTILE (I/1)
S710 1-771-410-21 SWITCH, TACTILE (SUR)
FRONT AMP PANEL
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
