Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
24
TA-S3
S711 1-771-410-21 SWITCH, TACTILE (EQ)
S712 1-771-410-21 SWITCH, TACTILE (MUSIC MODE, A)
S713 1-771-410-21 SWITCH, TACTILE (MOVIE MODE, B)
S714 1-771-410-21 SWITCH, TACTILE (2CH/MULTI, C)
S715 1-771-410-21 SWITCH, TACTILE (DIGITAL)
S718 1-771-410-21 SWITCH, TACTILE (SET UP)
S719 1-771-410-21 SWITCH, TACTILE (EQ ON/OFF)
S723 1-771-879-11 SWITCH, TACTILE (ENTER)
**************************************************************
1-680-755-11 RELAY BOARD
************
< CONNECTOR >
CN110 1-793-351-41 SOCKET, CONNECTOR 19P
(SYSTEM CONTROL 2 FROM ST-S3)
* CN111 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
**************************************************************
1-680-751-11 SUB TRANS BOARD
****************
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
* CN902 1-564-321-21 PIN, CONNECTOR 2P
CN903 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D901 8-719-911-19 DIODE 1SS133T-72
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R901 1-249-441-11 CARBON 100K 5% 1/4W
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T901 1-435-824-11 TRANSFORMER, POWER
**************************************************************
1-682-168-11 THP BOARD
**********
< CONNECTOR >
* CN999 1-564-517-11 PLUG, CONNECTOR 2P
< THERMISTOR (POSITIVE) >
THP841 1-807-796-11 THERMISTOR
**************************************************************
MISCELLANEOUS
**************
1 1-773-178-11 WIRE (FLAT TYPE) (23 CORE)
6 1-763-072-11 FAN, D. C.
0 109 1-777-071-81 CORD, POWER (AEP)
0 109 1-790-226-11 CORD, POWER (UK)
0 T911 1-435-936-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#3 7-685-872-09 SCREW +BVTT 3X8 (S)
#4 7-685-871-01 SCERW +BVTT 3X6 (S)
PANEL RELAY SUB TRANS THP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
