CPD-210GS/210EST
– 2 –
Failure Power LED
HV or H STOP or +B Failure Blink Amber (On 0.5 sec, Off 0.5 sec)
V Stop Failure Blink Amber (On 1.5 sec, Off 0.5 sec)
Aging/Self-Test Blink Amber (On 0.5 sec, Off 0.5 sec) .... Blink Green (On 0.5 sec, Off 0.5 sec)
Out of Range On Green (OSD Indication)
No Input Signal On Green (OSD Indication)
DIAGNOSIS
TIMING SPECIFICATION
PRIMARY MODE PRIMARY
MODE AT PRODUCTION MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7 MODE 8 MODE 9
RESOLUTION 640 X 480 640 X 480 720 X 400 800 X 600 800 X 600 832 X 624 1024 X 768 1024 X 768 1280 X 1024
CLOCK 25.175 MHZ 36.000 MHZ 28.322 MHZ 49.500 MHZ 56.250 MHZ 57.283 MHZ 78.750 MHZ 94.500 MHZ 108.000 MHZ
— HORIZONTAL —
H-FREQ 31.469 kHz 43.269 kHz 31.469 kHz 46.875 kHz 53.674 kHz 49.725 kHz 60.024 kHz 68.677 kHz 63.981 kHz
usec usec usec usec usec usec usec usec usec
H. TOTAL 31.778 23.111 31.777 21.333 18.631 20.111 16.660 14.561 15.630
H. BLK 6.356 5.333 6.355 5.172 4.409 5.586 3.657 3.725 3.778
H. FP 0.636 1.556 0.636 0.323 0.569 0.559 0.203 0.508 0.444
H. SYNC 3.813 1.556 3.813 1.616 1.138 1.117 1.219 1.016 1.037
H. BP 1.907 2.222 1.907 3.232 2.702 3.910 2.235 2.201 2.296
H. ACTIV 25.422 17.778 25.422 16.162 14.222 14.524 13.003 10.836 11.852
— VERTICAL —
V. FREQ(HZ) 59.940 Hz 85.008 Hz 70.087 Hz 75.000 Hz 85.061 Hz 74.550 Hz 75.030 Hz 84.997 Hz 60.020 Hz
lines lines lines lines lines lines lines lines lines
V. TOTAL 525 509 449 625 631 667 800 808 1066
V. BLK 45 29 49 25 31 43 32 40 42
V. FP 10112111111
V. SYNC 2 32333333
V. BP 33 25 35 21 27 39 28 36 38
V. ACTIV 480 480 400 600 600 624 768 768 1024
— SYNC —
INT(G) NO NO NO NO NO NO NO NO NO
EXT(H/V)/POLARITY YES -/- YES -/- YES -/+ YES +/+ YES +/+ YES -/- YES +/+ YES +/+ YES +/+
EXT(CS)/POLARITY NO NO NO NO NO NO NO NO NO
INT/NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT
98.12.10 VER.
Power mode Power
consumption
1 (power) indicator
normal
operation
≤ 110 W
(CPD-210GS)
≤ 105 W
(CPD-110GS)
green
1 standby ≤ 15 W green and orange
alternate
2 suspend ≤ 15 W green and orange
alternate
3 active off* ≤ 5 W orange
power off 0 W off
Power saving function
This monitor meets the power-saving guidelines set by VESA,
E NERGY S TAR, and NUTEK. If the monitor is connected to a
computer or video graphics board that is DPMS (Display Power
Management Signaling) compliant, the monitor will
automatically reduce power consumption in three stages as shown
below.
* When your computer enters the “active off” mode, the input signal is
cut and NO INPUT SIGNAL appears on the screen. After 20 seconds,
the monitor enters the power saving mode.
