Sony Trinitron CPD-210GS - Circuit Boards Location; Schematic Diagrams and Printed Wiring Boards

5-5
Note: The components identified by shading and mark
! are critical for safety. Replace only with part
number specified.
Note: Les composants identifiés per un tramé et une
marque ! sont critiques pour la sécurité. Ne les
remplacer que par une pièce portant le numéro
spécifié.
5-3. SCHEMATIC DIAGRAMS AND PRINTED
WIRING BOARDS
5-2. CIRCUIT BOARDS LOCATION
Note:
• All capacitors are in µF unless otherwise noted. (pF: µµF)
Capacitors without voltage indication are all 50 V.
• Indication of resistance, which does not have one for rating
electrical power, is as follows.
Pitch: 5 mm
Rating electrical power 1/4 W (CHIP : 1/10 W)
• All resistors are in ohms.
•
f : nonflammable resistor.
• F : fusible resistor.
•
¢ : internal component.
•
p : panel designation, and adjustment for repair.
• All variable and adjustable resistors have characteristic curve B,
unless otherwise noted.
•
e : earth-ground.
• E : earth-chassis.
• All voltages are in V.
• Readings are taken with a 10 M digital multimeter.
• Readings are taken with a color-bar signal input.
• Voltage variations may be noted due to normal production
tolerances.
•
*
: Can not be measured.
• Circled numbers are waveform references.
•
s : B + bus.
• S : B – bus.
• The components identified by
[ in this basic schematic diagram
have been carefully factory-selected for each set in order to
satisfy regulations regarding X-ray radiation.
Should replacement be required, replace only with the value
originally used.
• When replacing components identified by
], make the
necessary adjustments indicated. (See page 3-1)
• When replacing the part in below table, be sure to perform the
related adjustment.
D
A
HV Regulator
Circuit Check
HV Hold-down
Circuit Check
Beam Current
Protector Circuit
Check
Part replaced ( ] )
D Board IC502, IC503, C501
C535, C553, C597
C598, R592, R593
R596, RV501,
T501 (FBT)
D Board IC501, D521, C585
C599, R598, R599
R5C7, T501 (FBT)
D Board Q533, D592, C590
C591, C598, R5A5
R5C0, R5C3, L502
T501 (FBT)
HV ADJ
Part replaced ( [ )
RV501
• Divided circuit diagram
One sheet of D board circuit diagram is divided into three
sheets, each having the code D-a to D-c . For example, the
destination ab1 on the D-a sheet is connected to ab1 on the
D-b sheet.
ab1
Circuit diagram division code
Ref. No.
