REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
CPD-210GS/210EST
7-8
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
(d)
The components identified by [ in this manual
have been carefully factory-selected for each set
in order to satisfy regulations regarding X-ray
radiation. Should replacement be required,
replace only with the value originally used.
R926 1-247-791-91 CARBON 22 5% 1/4W
R927 1-247-903-00 CARBON 1M 5% 1/4W
R928 1-249-429-11 CARBON 10K 5% 1/4W
R929 1-249-429-11 CARBON 10K 5% 1/4W
R930 1-249-429-11 CARBON 10K 5% 1/4W
R931 1-249-413-11 CARBON 470 5% 1/4W
R932 1-249-413-11 CARBON 470 5% 1/4W
R933 1-249-425-11 CARBON 4.7K 5% 1/4W
R934 1-249-425-11 CARBON 4.7K 5% 1/4W
R935 1-249-408-11 CARBON 180 5% 1/4W
R936 1-249-408-11 CARBON 180 5% 1/4W
R949 1-249-429-11 CARBON 10K 5% 1/4W
R950 1-249-429-11 CARBON 10K 5% 1/4W
R951 1-249-429-11 CARBON 10K 5% 1/4W
R954 1-247-791-91 CARBON 22 5% 1/4W
R955 1-249-425-11 CARBON 4.7K 5% 1/4W
R956 1-249-417-11 CARBON 1K 5% 1/4W
R959 1-247-791-91 CARBON 22 5% 1/4W
R960 1-247-791-91 CARBON 22 5% 1/4W
R961 1-240-890-11 METAL 1K 1% 1/4W
R962 1-247-791-91 CARBON 22 5% 1/4W
R963 1-249-429-11 CARBON 10K 5% 1/4W
R964 1-247-791-91 CARBON 22 5% 1/4W
R965 1-249-429-11 CARBON 10K 5% 1/4W
R967 1-249-428-11 CARBON 8.2K 5% 1/4W
R968 1-249-425-11 CARBON 4.7K 5% 1/4W
R969 1-249-417-11 CARBON 1K 5% 1/4W
R970 1-249-425-11 CARBON 4.7K 5% 1/4W
R971 1-249-417-11 CARBON 1K 5% 1/4W
R972 1-249-425-11 CARBON 4.7K 5% 1/4W
R973 1-249-417-11 CARBON 1K 5% 1/4W
R974 1-240-888-11 METAL 33.2 1% 1/4W
R975 1-240-907-11 METAL 30.1K 1% 1/4W
R976 1-240-901-11 METAL 9.31K 1% 1/4W
R977 1-240-903-11 METAL 13.3K 1% 1/4W
R978 1-249-441-11 CARBON 100K 5% 1/4W
R979 1-249-441-11 CARBON 100K 5% 1/4W
<NETWORK RESISTOR>
RN901 1-234-276-11 RES, NETWORKS
RN902 1-234-277-11 RES, NETWORKS
<VARIABLE RESISTOR>
[ RV501¡1-241-767-21RES, ADJ, CERMET 100K (HV ADJ)
<RELAY>
RY601¡1-755-031-11RELAY
<SWITCH>
S601 ¡ 1-771-668-11 SWITCH, AC POWER PUSH
S901 1-771-670-11 SWITCH, TACTILE (MENU/ENTER)
S902 1-771-670-11 SWITCH, TACTILE (RIGHT +)
S903 1-771-670-11 SWITCH, TACTILE (LEFT -)
<SPARK GAP>
SG501 1-519-422-11 GAP, SPARK
<TRANSFORMER>
T501 ¡ 1-453-301-11 TRANSFORMER, FLYBACK
T502 1-431-248-11 TRANSFORMER, FERRITE (HDT)
T503 1-433-799-11 TRANSFORMER, FERRITE (HST)
T504 1-429-109-11 TRANSFORMER, FERRITE (DFT)
T601
T603 ¡ 1-433-796-11 TRANSFORMER
<THERMISTOR>
TH601¡1-803-533-11THERMISTOR
* 1-506-371-00 PIN, CONNECTOR 2P; TH601
TH602¡1-809-827-11THERMISTOR, POSITIVE
<CRYSTAL>
X901 1-781-365-11 VIBRATOR, CRYSTAL
– 48 –
Sony Corporation
Computer Display Company
Computer Display Div.
9-978-639-02
English
99HL24-Data
Made in Japan
© 1999.8
