REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-2
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-200PS/200PST/200PST9
CN404*1-564-521-11 PLUG, CONNECTOR 6P
CN405*1-766-179-11 PIN, CONNECTOR (PC BOARD) 2P
CN406*1-564-522-11 PLUG, CONNECTOR 7P
CN409 1-695-915-11 TAB (CONTACT)
<DIODE>
D101 8-719-062-51 DIODE 1PS226-115
D103 8-719-051-85 DIODE HSS83TD
D104 8-719-051-85 DIODE HSS83TD
D105 8-719-052-12 DIODE 1SS376TE-17
D106 8-719-404-50 DIODE MA111-TX
D111 8-719-062-51 DIODE 1PS226-115
D201 8-719-062-51 DIODE 1PS226-115
D203 8-719-051-85 DIODE HSS83TD
D204 8-719-051-85 DIODE HSS83TD
D205 8-719-052-12 DIODE 1SS376TE-17
D206 8-719-404-50 DIODE MA111-TX
D211 8-719-062-51 DIODE 1PS226-115
D301 8-719-062-51 DIODE 1PS226-115
D303 8-719-051-85 DIODE HSS83TD
D304 8-719-051-85 DIODE HSS83TD
D305 8-719-052-12 DIODE 1SS376TE-17
D306 8-719-404-50 DIODE MA111-TX
D311 8-719-062-51 DIODE 1PS226-115
D401 8-719-109-85 ZENER DIODE RD5.1ESB2
D402 8-719-404-50 DIODE MA111-TX
D406 8-719-911-19 DIODE 1SS119-25
D413 8-719-911-19 DIODE 1SS119-25
D414 8-719-109-66 ZENER DIODE RD3.3ESB2
D415 8-719-051-85 DIODE HSS83TD
<FERRITE BEAD>
FB101 1-500-419-21 FERRITE
FB201 1-500-419-21 FERRITE
FB301 1-500-419-21 FERRITE
FB404 1-412-911-31 FERRITE 1.1µH
FB405 1-412-911-31 FERRITE 1.1µH
FB406 1-412-911-31 FERRITE 1.1µH
FB408 1-412-911-31 FERRITE 1.1µH
FB414 1-412-911-31 FERRITE 1.1µH
<IC>
IC401 8-759-635-27 IC M62352GP-75E
IC402 8-759-925-72 IC SN74HC02ANS
IC403 8-759-445-85 IC LM1283N
IC404 8-759-566-26 IC LSC4380DW2AR2
IC405 8-759-502-82 IC LM324M
IC406 8-759-263-43 IC TA78M12S
IC407 8-759-435-33 IC LM2405T
IC408 8-759-522-86 IC M52755FP-TP
<JACK>
J401 ¡ 1-251-598-11 SOCKET, PICTURE TUBE
<COIL>
L401 1-412-537-31 INDUCTOR 100µH
L402 1-408-615-31 INDUCTOR 100µH
L404 1-414-189-31 INDUCTOR 100µH
<IC LINK>
PS401¡1-533-590-31LINK, IC (1A/90V AC, 60V DC)
PS402¡1-532-637-91LINK, IC (1A/150V)
<TRANSISTOR>
Q101 8-729-041-66 TRANSISTOR 2SC4015TV2
Q102 8-729-200-17 TRANSISTOR 2SA1091-O
Q201 8-729-041-66 TRANSISTOR 2SC4015TV2
Q202 8-729-200-17 TRANSISTOR 2SA1091-O
Q301 8-729-041-66 TRANSISTOR 2SC4015TV2
Q302 8-729-200-17 TRANSISTOR 2SA1091-O
Q401 8-729-901-00 TRANSISTOR DTC124EK
Q402 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q404 8-729-207-72 TRANSISTOR 2SA1037K-T-146-QR
Q405 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q406 8-729-207-72 TRANSISTOR 2SA1037K-T-146-QR
Q409 8-729-207-72 TRANSISTOR 2SA1037K-T-146-QR
Q410 8-729-032-61 TRANSISTOR 2SC5022-02
<RESISTOR>
R101 1-215-395-00 METAL 82 1% 1/4W
R103 1-216-049-00 RES,CHIP 1K 5% 1/10W
R104 1-216-121-91 RES,CHIP 1M 5% 1/10W
R105 1-216-001-00 RES,CHIP 10 5% 1/10W
R106 1-216-019-00 RES,CHIP 56 5% 1/10W
R107 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R108 1-219-742-11 CARBON 47 5% 1/2W
R109 1-216-039-00 RES,CHIP 390 5% 1/10W
R110 1-216-689-11 RES,CHIP 39K 5% 1/10W
R111 1-216-089-00 RES,CHIP 47K 5% 1/10W
R112 1-216-121-91 RES,CHIP 1M 5% 1/10W
R113 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R114 1-216-097-00 RES,CHIP 100K 5% 1/10W
R115 1-216-049-00 RES,CHIP 1K 5% 1/10W
R116 1-216-097-00 RES,CHIP 100K 5% 1/10W
R117 1-216-049-00 RES,CHIP 1K 5% 1/10W
R118 1-216-689-11 RES,CHIP 39K 5% 1/10W
R121 1-216-081-00 RES,CHIP 22K 5% 1/10W
R124 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R132 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R140 1-216-017-91 RES,CHIP 47 5% 1/10W
R141 1-216-009-91 RES,CHIP 22 5% 1/10W
R161 1-215-395-00 METAL 82 1% 1/4W
R163 1-216-017-91 RES,CHIP 47 5% 1/10W
