Sony Trinitron GDM-200PS - 7 Electrical Parts List

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-1
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-200PS/200PST/200PST9
NOTE:
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
When indicating parts by reference number,
please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
RESISTORS
• All resistors are in ohms
• F : nonflammable
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be
anticipated when ordering these items.
The components identified by [ in this
manual have been carefully factory-
selected for each set in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
A
* A-1298-233-BA BOARD, COMPLETE
****************************
4-382-854-11 SCREW (M3X10), P, SW (+) (IC406, IC407)
<CAPACITOR>
C103 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C104 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C106 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C107 1-107-649-11 ELECT 2.2µF 20% 250V
C109 1-117-450-11 FILM 0.47µF 10% 250V
C120 1-104-664-11 ELECT 47µF 20% 25V
C124 1-163-263-11 CERAMIC CHIP 330pF 5% 50V
C130 1-115-340-11 CERAMIC CHIP 0.22µF 10% 25V
C152 1-104-664-11 ELECT 47µF 20% 25V
C203 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C204 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C206 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C207 1-107-649-11 ELECT 2.2µF 20% 250V
C209 1-117-450-11 FILM 0.47µF 10% 250V
C220 1-104-664-11 ELECT 47µF 20% 25V
C224 1-163-263-11 CERAMIC CHIP 330pF 5% 50V
C230 1-115-340-11 CERAMIC CHIP 0.22µF 10% 25V
C252 1-104-664-11 ELECT 47µF 20% 25V
C303 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C304 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C306 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C307 1-107-649-11 ELECT 2.2µF 20% 250V
C309 1-117-450-11 FILM 0.47µF 10% 250V
C320 1-104-664-11 ELECT 47µF 20% 25V
C324 1-163-263-11 CERAMIC CHIP 330pF 5% 50V
C330 1-115-340-11 CERAMIC CHIP 0.22µF 10% 25V
C352 1-104-664-11 ELECT 47µF 20% 25V
C401 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C402 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C403 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C404 1-104-664-11 ELECT 47µF 20% 25V
C405 1-107-928-11 ELECT 4.7µF 20% 100V
C406 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C407 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C408 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C409 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C410 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C411 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C413 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C414 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C415 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C418 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C420 1-163-222-11 CERAMIC CHIP 5pF 0.25pF50V
C421 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C422 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C424 1-104-664-11 ELECT 47µF 20% 25V
C425 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C427 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C429 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C430 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C432 1-107-652-11 ELECT 10µF 20% 200V
C433 1-104-664-11 ELECT 47µF 20% 25V
C435 1-104-664-11 ELECT 47µF 20% 25V
C436 1-104-664-11 ELECT 47µF 20% 25V
C437 1-104-665-11 ELECT 100µF 20% 25V
C438 1-162-114-00 CERAMIC 0.0047µF 2KV
C440 1-162-318-11 CERAMIC 0.001µF 10% 500V
C441 1-162-318-11 CERAMIC 0.001µF 10% 500V
C442 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C443 1-104-665-11 ELECT 100µF 20% 25V
C445 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C446 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C447 1-104-664-11 ELECT 47µF 20% 25V
C448 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C450 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C452 1-104-664-11 ELECT 47µF 20% 25V
C453 1-128-562-11 ELECT 47µF 20% 100V
C454 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C455 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C458 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C459 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C460 1-104-664-11 ELECT 47µF 20% 25V
C462 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
<CONNECTOR>
CN401*1-564-520-11 PLUG, CONNECTOR 5P
CN402*1-564-524-11 PLUG, CONNECTOR 9P
CN403*1-564-522-11 PLUG, CONNECTOR 7P
