POWER SAVING FUNCTION
This monitor is capable of three states of reduced power consumption. By sensing the absence of video signals and one or both sync signals
coming from the host computer, it will reduce power consumption as follows.
Power consumption state
1 Normal operation
2 Standby (1st state)
3 Suspend (2nd state)
4 Active-off (3rd state)
5 Power-off
Power consumption
≤120 W
≤85 W
≤15 W
≤5 W
0 W
u power indicator
Green on
Green and orange alternate
Green and orange alternate
Orange on
Off
Recovery time
–
Approx. 1 sec.
Approx. 3 sec.
Approx. 15 sec.
–
DIAGNOSIS
Failre
+B failure
Horizontal / Vertical Deflection failure,
Thermal protector
ABL protector
HV failure
Aging / Self Test
Power LED
Amber → Off
(0.5 sec) (0.5 sec)
Amber → Off
(1.5 sec) (0.5 sec)
Amber → Off
(0.5 sec) (1.5 sec)
Amber → Off → Amber → Off
(0.25 sec) (0.5 sec) (0.25 sec) (1.25 sec)
Amber → Off → Green → Off
(0.5 sec) (0.5 sec) (0.5 sec) (0.5 sec)
Aging Mode (Video Aging) : During Power Save, press “MENU” key for longer than 2 second.
Self Test (OSD Color Bar) : During Power Save, press “CONTRAST” + (>) key for longer than 2 second.
Reliability Check Mode : During Power Save, press “CONTRAST”– (.) key for longer than 2 second.
TIMING SPECIFICATION
MODE AT PRODUCTION MODE 1 MODE 2
RESOLUTION 1280 X 960 1280 X 1024
CLOCK 148.500 MHz 135.000 MHz
— HORIZONTAL —
H-FREQ 85.938 kHz 79.976 kHz
usec usec
H. TOTAL 11.636 12.504
H. BLK 3.017 3.022
H. FP 0.431 0.119
H. SYNC 1.077 1.067
H. BP 1.508 1.837
H. ACTIV 8.620 9.481
— VERTICAL —
V. FREQ(Hz) 85.002 Hz 75.025 Hz
lines lines
V. TOTAL 1011 1066
V. BLK 51 42
V. FP 1 1
V. SYNC 3 3
V. BP 47 38
V. ACTIV 960 1024
— SYNC —
INT(G) NO NO
EXT(H/V)/POLARITY YES P/P YES P/P
EXT(CS)/POLARITY NO NO
INT/NON INT NON INT NON INT
