REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-4
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-200PS/200PST/200PST9
SG402 1-519-422-11 GAP, SPARK
*********************************************************************************
* A-1346-659-BD BOARD, COMPLETE
****************************
1-533-223-11 HOLDER, FUSE (F601)
2-371-561-00 BUSHING (P), INSULATING
(IC502, IC1504)
3-710-578-01 COVER, VOLUME, 6 MOLD (RV901)
4-039-357-01 SCREW (3X8), (+) BV TAPPING
4-045-133-21 HOLDER (B), LED (D006, D009)
* 4-049-002-01 HOLDER, LED (D003)
4-061-191-01 SHEET, INSULATE (IC502, IC1504)
4-061-192-01 SHEET, INSULATE (Q906)
4-382-854-11 SCREW (M3X10), P, SW (+)
(IC502, IC603, IC1504, Q514, Q519, Q905,
Q906, D511, D601, D603, D617, R539, R919)
4-812-134-00 RIVET (DIA. 3.5), NYLON
<CAPACITOR>
C001 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C002 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C003 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C004 1-104-664-11 ELECT 47µF 20% 25V
C005 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C006 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C007 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C008 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C009 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C010 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C011 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C012 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C013 1-104-664-11 ELECT 47µF 20% 25V
C014 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C015 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C016 1-104-664-11 ELECT 47µF 20% 25V
C017 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C021 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C022 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C023 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C024 1-104-664-11 ELECT 47µF 20% 25V
C025 1-104-664-11 ELECT 47µF 20% 25V
C026 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C027 1-126-961-11 ELECT 2.2µF 20% 50V
C028 1-104-664-11 ELECT 47µF 20% 25V
C029 1-126-935-11 ELECT 470µF 20% 16V
C030 1-137-372-11 FILM 0.022µF 5% 50V
C031 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C032 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C036 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C037 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C038 1-126-960-11 ELECT 1µF 20% 50V
C040 1-163-137-00 CERAMIC CHIP 680pF 5% 50V
C041 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C042 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C043 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C044 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C045 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C046 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C047 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C048 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C049 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C050 1-137-194-81 FILM 0.47µF 5% 50V
C051 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C052 1-126-963-11 ELECT 4.7µF 20% 50V
C053 1-126-960-11 ELECT 1µF 20% 50V
C054 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C055 1-126-964-11 ELECT 10µF 20% 50V
C056 1-126-964-11 ELECT 10µF 20% 50V
C057 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C058 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C059 1-163-257-11 CERAMIC CHIP 180pF 5% 50V
C060 1-126-964-11 ELECT 10µF 20% 50V
C061 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C062 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C063 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C064 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C065 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C066 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C067 1-126-964-11 ELECT 10µF 20% 50V
C069 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C070 1-130-495-00 FILM 0.1µF 5% 50V
C071 1-126-960-11 ELECT 1µF 20% 50V
C072 1-130-495-00 FILM 0.1µF 5% 50V
C073 1-126-964-11 ELECT 10µF 20% 50V
C074 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C075 1-104-665-11 ELECT 100µF 20% 25V
C076 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C077 1-126-791-11 ELECT 10µF 20% 16V
C078 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C079 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C081 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C083 1-104-664-11 ELECT 47µF 20% 25V
C084 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C085 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C086 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C087 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C088 1-164-232-11 CERAMIC CHIP 0.01µF 10% 50V
C501 1-163-005-11 CERAMIC CHIP 470pF 10% 50V
C502 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C503 1-126-967-11 ELECT 47µF 20% 50V
C504 1-137-194-81 FILM 0.47µF 5% 50V
C505 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C506 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C507 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C509 1-104-664-11 ELECT 47µF 20% 25V
C510 1-126-941-11 ELECT 470µF 20% 25V
C511 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C512 1-110-641-51 ELECT 33µF 20% 200V
C514 1-164-281-11 CERAMIC 0.001µF 2KV
A(d)
