REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-6
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-200PS/200PST/200PST9
C918 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C919 1-137-368-11 FILM 0.0047µF 5% 50V
C920 1-117-626-31 FILM 2000pF 3% 1.2KV
C921 1-137-372-11 FILM 0.022µF 5% 50V
C922 1-106-228-00 MYLAR 0.22µF 10% 100V
C923 1-106-220-00 MYLAR 0.1µF 10% 100V
C924 1-106-355-12 MYLAR 0.0033µF 10% 200V
C925 1-106-220-00 MYLAR 0.1µF 10% 100V
C926 1-115-516-11 FILM 0.33µF 5% 250V
C927 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C928 1-104-665-11 ELECT 100µF 20% 25V
C929 1-106-383-00 MYLAR 0.047µF 10% 200V
C931 1-126-964-11 ELECT 10µF 20% 50V
C932 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C933 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C935 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C936 1-126-967-11 ELECT 47µF 20% 50V
C1501 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1502 1-130-495-00 FILM 0.1µF 5% 50V
C1503 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1504 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C1505 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C1506 1-104-664-11 ELECT 47µF 20% 25V
C1507 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1508 1-130-495-00 FILM 0.1µF 5% 50V
C1509 1-104-664-11 ELECT 47µF 20% 25V
C1513 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C1514 1-107-914-11 ELECT 1000µF 20% 25V
C1515 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C1516 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1517 1-107-894-11 ELECT 220µF 20% 35V
C1518 1-107-914-11 ELECT 1000µF 20% 25V
C1519 1-106-228-00 MYLAR 0.22µF 10% 100V
<CONNECTOR>
CN501*1-508-879-11 BASE POST
CN502*1-564-515-11 PLUG, CONNECTOR 12P
CN503*1-564-595-11 PLUG, CONNECTOR 14P
CN504*1-564-510-11 PLUG, CONNECTOR 7P
CN505 1-764-101-11 PIN, CONNECTOR (PC BOARD) 2P
CN506*1-779-465-11 PIN, CONNECTOR (WITH PWB) 6P
CN507*1-564-509-11 PLUG, CONNECTOR 6P
CN601*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN602*1-784-222-11 PIN, CONNECTOR (WITH PWB)
<DIODE>
D001 8-719-109-85 ZENER DIODE RD5.1ESB2
D003 8-719-045-19 DIODE SPB-26MVWF
D005 8-719-109-85 ZENER DIODE RD5.1ESB2
D006 8-719-311-90 DIODE SEL1922D-C
D009 8-719-311-90 DIODE SEL1922D-C
D010 8-719-109-85 ZENER DIODE RD5.1ESB2
D011 8-719-976-99 ZENER DIODE DTZ5.1B
D012 8-719-976-99 ZENER DIODE DTZ5.1B
D013 8-719-106-23 ZENER DIODE RD7.5M-B2
D014 8-719-404-50 DIODE MA111-TX
D017 8-719-404-50 DIODE MA111-TX
D018 8-719-109-85 ZENER DIODE RD5.1ESB2
D020 8-719-062-51 DIODE 1PS226-115
D021 8-719-062-51 DIODE 1PS226-115
D022 8-719-062-51 DIODE 1PS226-115
D023 8-719-062-51 DIODE 1PS226-115
D024 8-719-109-96 ZENER DIODE RD6.8ESB1
D028 8-719-109-85 ZENER DIODE RD5.1ESB2
D030 8-719-801-78 DIODE 1SS184
D503 8-719-911-19 DIODE 1SS119-25
D504 8-719-404-50 DIODE MA111-TX
D505 8-719-110-02 ZENER DIODE RD7.5ESB1
D506 8-719-977-40 ZENER DIODE DTZ13B
D507 8-719-404-50 DIODE MA111-TX
D508 8-719-052-86 DIODE D2L40-TA
D509 8-719-404-50 DIODE MA111-TX
D510 8-719-975-77 DIODE SB340
D511 8-719-061-21 DIODE FMQ-G5FMS
D512 8-719-109-85 ZENER DIODE RD5.1ESB2
D513 8-719-109-85 ZENER DIODE RD5.1ESB2
D514 8-719-911-19 DIODE 1SS119-25
D515 8-719-911-19 DIODE 1SS119-25
D516 8-719-028-72 DIODE RGP02-17EL-6433
D517 8-719-951-30 DIODE ERA91-02
D518 8-719-404-50 DIODE MA111-TX
D519 8-719-911-19 DIODE 1SS119-25
D520 8-719-948-45 DIODE ERA22-08
D522 8-719-911-19 DIODE 1SS119-25
D523 8-719-911-19 DIODE 1SS119-25
D524 8-719-028-72 DIODE RGP02-17EL-6433
D525 8-719-109-93 ZENER DIODE RD6.2ESB2
D601 ¡ 8-719-510-53 DIODE D4SB60L
D602 8-719-911-19 DIODE 1SS119-25
D603 8-719-029-04 DIODE D5L60
D604 8-719-510-02 DIODE D1NS4
D606 8-719-979-64 DIODE UF4005PKG23
D607 8-719-110-31 ZENER DIODE RD12ESB2
D608 8-719-911-19 DIODE 1SS119-25
D609 8-719-302-43 DIODE EL1Z
D610 8-719-947-06 DIODE RGP10JPKG23
D611 8-719-066-51 DIODE P6KE170AG23
D612 8-719-028-45 DIODE D2L20U
D613 8-719-022-97 DIODE D2S4MF
D614 8-719-510-64 DIODE S2LA20F
D615 8-719-052-86 DIODE D2L40-TA
D616 8-719-052-86 DIODE D2L40-TA
D617 8-719-052-91 DIODE D4SBS4-F
D619 8-719-022-97 DIODE D2S4MF
D620 8-719-110-63 ZENER DIODE RD24ESB3
D621 8-719-911-19 DIODE 1SS119-25
D622 8-719-110-31 ZENER DIODE RD12ESB2
D623 8-719-404-50 DIODE MA111-TX
D624 8-719-977-28 ZENER DIODE DTZ10B
D902 8-719-158-49 ZENER DIODE RD12SB2
D903 8-719-404-50 DIODE MA111-TX
