REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-8
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-200PS/200PST/200PST9
Q518 8-729-041-95 TRANSISTOR IRLI540GLF33
Q519 8-729-041-64 TRANSISTOR BU2527AX-ON5020
Q520 8-729-041-93 TRANSISTOR IRLI530GLF33
Q521 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q522 8-729-041-93 TRANSISTOR IRLI530GLF33
Q523 8-729-041-93 TRANSISTOR IRLI530GLF33
Q524 8-729-041-93 TRANSISTOR IRLI530GLF33
Q525 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q527 8-729-033-25 TRANSISTOR DTC114GKA
Q528 8-729-204-91 TRANSISTOR 2SA1049-GR
Q529 8-729-178-43 TRANSISTOR 2SC2784-E
Q530 8-729-207-89 TRANSISTOR 2SA1358-Y
Q531 8-729-207-82 TRANSISTOR 2SC3421-Y
Q532 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q601 8-729-033-25 TRANSISTOR DTC114GKA
Q602 8-729-029-40 TRANSISTOR DTA124ESA
Q603 8-729-033-25 TRANSISTOR DTC114GKA
Q604 8-729-033-26 TRANSISTOR DTA114GKAT146
Q605 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q901 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q903 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q904 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q905 8-729-035-54 TRANSISTOR 2SJ449
Q906 8-729-041-94 TRANSISTOR IRFPE50LF21
<RESISTOR>
R001 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R003 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R005 1-216-025-00 RES,CHIP 100 5% 1/10W
R006 1-216-049-00 RES,CHIP 1K 5% 1/10W
R007 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R008 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R009 1-216-049-00 RES,CHIP 1K 5% 1/10W
R011 1-216-049-00 RES,CHIP 1K 5% 1/10W
R012 1-216-045-00 RES,CHIP 680 5% 1/10W
R013 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R015 1-216-017-91 RES,CHIP 47 5% 1/10W
R016 1-216-041-00 RES,CHIP 470 5% 1/10W
R017 1-216-041-00 RES,CHIP 470 5% 1/10W
R018 1-216-017-91 RES,CHIP 47 5% 1/10W
R019 1-216-037-00 RES,CHIP 330 5% 1/10W
R020 1-216-037-00 RES,CHIP 330 5% 1/10W
R023 1-216-025-00 RES,CHIP 100 5% 1/10W
R026 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R027 1-216-049-00 RES,CHIP 1K 5% 1/10W
R028 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R029 1-216-049-00 RES,CHIP 1K 5% 1/10W
R030 1-216-041-00 RES,CHIP 470 5% 1/10W
R031 1-216-049-00 RES,CHIP 1K 5% 1/10W
R032 1-216-049-00 RES,CHIP 1K 5% 1/10W
R033 1-216-037-00 RES,CHIP 330 5% 1/10W
R034 1-216-049-00 RES,CHIP 1K 5% 1/10W
R035 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R036 1-216-073-00 RES,CHIP 10K 5% 1/10W
R037 1-216-049-00 RES,CHIP 1K 5% 1/10W
R038 1-216-049-00 RES,CHIP 1K 5% 1/10W
R039 1-216-049-00 RES,CHIP 1K 5% 1/10W
R040 1-216-037-00 RES,CHIP 330 5% 1/10W
R042 1-216-073-00 RES,CHIP 10K 5% 1/10W
R043 1-216-037-00 RES,CHIP 330 5% 1/10W
R044 1-216-295-00 SHORT 0
R045 1-216-295-00 SHORT 0
R046 1-216-295-00 SHORT 0
R048 1-216-073-00 RES,CHIP 10K 5% 1/10W
R049 1-216-073-00 RES,CHIP 10K 5% 1/10W
R051 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R052 1-216-025-00 RES,CHIP 100 5% 1/10W
R053 1-216-097-00 RES,CHIP 100K 5% 1/10W
R055 1-216-089-00 RES,CHIP 47K 5% 1/10W
R056 1-216-017-91 RES,CHIP 47 5% 1/10W
R057 1-216-025-00 RES,CHIP 100 5% 1/10W
R058 1-216-049-00 RES,CHIP 1K 5% 1/10W
R059 1-216-089-00 RES,CHIP 47K 5% 1/10W
R061 1-216-073-00 RES,CHIP 10K 5% 1/10W
R062 1-216-025-00 RES,CHIP 100 5% 1/10W
R063 1-216-025-00 RES,CHIP 100 5% 1/10W
R065 1-216-105-91 RES,CHIP 220K 5% 1/10W
R066 1-216-073-00 RES,CHIP 10K 5% 1/10W
R067 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R068 1-216-073-00 RES,CHIP 10K 5% 1/10W
R069 1-216-049-00 RES,CHIP 1K 5% 1/10W
R070 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R071 1-216-295-00 SHORT 0
R072 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R073 1-216-073-00 RES,CHIP 10K 5% 1/10W
R074 1-216-049-00 RES,CHIP 1K 5% 1/10W
R075 1-216-681-11 METAL CHIP 18K 0.50%1/10W
R076 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R077 1-216-049-00 RES,CHIP 1K 5% 1/10W
R078 1-216-073-00 RES,CHIP 10K 5% 1/10W
R079 1-216-049-00 RES,CHIP 1K 5% 1/10W
R080 1-216-049-00 RES,CHIP 1K 5% 1/10W
R081 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R082 1-216-073-00 RES,CHIP 10K 5% 1/10W
R083 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R084 1-216-073-00 RES,CHIP 10K 5% 1/10W
R086 1-216-073-00 RES,CHIP 10K 5% 1/10W
R087 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R089 1-216-025-00 RES,CHIP 100 5% 1/10W
R090 1-216-025-00 RES,CHIP 100 5% 1/10W
R091 1-216-025-00 RES,CHIP 100 5% 1/10W
R092 1-216-025-00 RES,CHIP 100 5% 1/10W
R093 1-216-025-00 RES,CHIP 100 5% 1/10W
R094 1-216-025-00 RES,CHIP 100 5% 1/10W
R095 1-216-025-00 RES,CHIP 100 5% 1/10W
R096 1-216-025-00 RES,CHIP 100 5% 1/10W
R098 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R099 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R501 1-216-097-00 RES,CHIP 100K 5% 1/10W
R502 1-216-049-00 RES,CHIP 1K 5% 1/10W
R503 1-216-097-00 RES,CHIP 100K 5% 1/10W
