REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-11
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés par un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
GDM-200PS/200PST/200PST9
D
R1531 1-214-798-21 METAL 1.8 1% 1/2W
R1532 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1533 1-216-657-11 METAL CHIP 1.8K 0.50%1/10W
R1534 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R1535 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R1536 1-249-413-11 CARBON 470 5% 1/4W F
R1537 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R1538 1-215-866-11 METAL OXIDE 330 5% 1W F
R1539 1-249-381-11 CARBON 1 5% 1/4W F
R1540 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R1541 1-214-798-21 METAL 1.8 1% 1/2W
R1542 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
<VARIABLE RESISTOR>
[ RV901¡1-241-767-21RES, ADJ, CERMET 100K (HV ADJ)
<RELAY>
RY501 1-755-137-11 RELAY
RY601 1-515-840-11 RELAY
RY602 1-515-669-21 RELAY
<SWITCH>
S001 1-571-532-21 SWITCH, TACTILE (CONT+)
S002 1-571-532-21 SWITCH, TACTILE (CONT-)
S003 1-571-532-21 SWITCH, TACTILE (OSD)
S004 1-571-532-21 SWITCH, TACTILE (BRT+)
S005 1-571-532-21 SWITCH, TACTILE (BRT-)
S006 1-571-532-21 SWITCH, TACTILE (INPUT)
S007 1-571-532-21 SWITCH, TACTILE (ASC)
S008 1-571-532-21 SWITCH, TACTILE (RESET)
SW601¡1-571-433-31SWITCH, PUSH (AC POWER)
<SPARK GAP>
SG901 1-519-422-11 GAP, SPARK
SG902 1-517-499-21 GAP, SPARK
<TRANSFORMER>
T501 1-431-056-11 TRANSFORMER, HORIZONTAL DRIVE
T502 1-431-414-11 TRANSFORMER, FERRITE (DFT)
T503 1-411-594-11 INDUCTOR 5mH
T504 1-431-443-11 TRANSFORMER, FERRITE (HST)
T505 1-429-301-11 TRANSFORMER, FERRITE (HCT)
T601 ¡ 1-429-180-11 TRANSFORMER, LINE FILTER
T602 1-431-445-11 TRANSFORMER, CONVERTER (PFT)
T603 1-431-416-11 TRANSFORMER, CONVERTER (SRT)
T604 ¡ 1-431-446-12 TRANSFORMER, CONVERTER (PIT)
T901 ¡ X-4035-177-1 TRANSFORMER ASSY, FLYBACK
(NX-4401//J1M4)
T902 1-411-567-11 INDUCTOR 500µH
<THERMISTOR>
TH501 1-807-796-11THERMISTOR
TH601¡1-809-260-11THERMISTOR, POWER
THP6011-809-827-11 THERMISTOR, POSITIVE
<VARISTOR>
VDR601 1-810-622-11VARISTOR
VDR602¡1-801-268-51VARISTOR TNR14V471K660
<CRYSTAL>
X001 1-567-781-61 VIBRATOR, CRYSTAL (4MHz)
The components identified by [ in this manual
have been carefully factory-selected for each set
in order to satisfy regulations regarding X-ray
radiation. Should replacement be required,
replace only with the value originally used.
