Sony TRINITRON KD-27FS170 - KD-36 FS170 Models Only

KD-27FS170/32FS170/36FS170
KD-27FS170/32FS170/36FS170
70
KD-36FS170 MODELS ONLY
( = ) Means not memorized in NVM
Version 1.0
NTSC Video YUV Digital
Init Init Init Init
Data Data Data Data
VERSION Fix 0 ====
VAR
1HSIZ
H SIZE
(
EW DC
)
28 29 29 29
VAR
2 HPOS H POSITION 19 20 20 11
VAR
3 VSIZ V RAMP SIZE 27
28 29 26
VAR
4 VPOS
V POSITION
(
RAMP DC
)
32 32 32 30
VAR
5VLIN
V LINEARITY
38
VAR
6SCOR
S CORRECTION
51
VAR
7 VBOW
BOW
45
VAR
8 VANG
ANGLE
37
VAR
9TRAP
EW TRAPESIUM
33
VAR
10 PAMP
EW PIN
31
VAR
11 UPIN
UPPER PIN
28
VAR
12 LPIN
LOWER PIN
28
VAR
13 TROT TROT 109
VAR
14 HBL
K
H BLK mode select
0
VAR
15 RBL
K
HBLK rear timin
g
29
29 29 21
VAR
16 LBL
K
HBLK front timin
g
59
59 59 54
VAR
17 VBL
K
V BLK width
3
FIX
18 HMS
K
TOP VEND
(
when MACROVISION
)p
revent OFF 0
FIX
19 HDW
H PULSE WIDTH
(
25u 19u
)
1
FIX
20 AFC
AFC GAIN
0
FIX
21 AFC1
AFC1 TIME CONSTANT
3
FIX
21 AFC1
AFC1 TIME CONSTANT 33 3
FIX
22 AFCW
AFC1 PULL IN WIDE
1
FIX
23 CDMD V DET WINDOW SW TIMING 1
FIX
24 HSS
SYNC SLICE LEVEL(H sepa)
0
FIX
25 VSS
SYNC SLICE LEVEL(V sepa)
3
FIX
26 SLUD
Auto Slice level UP DOWN
0
FIX
27 JPSW
Jump SW
0
FIX
28 HOSC
H VCO fo offset ADJUST OFFSET
3
FIX
29 EHT EHT 4
FIX
30 EHTG EHT MODE 1
FIX
31 SLOH
LPF SYNC H
1
FIX
32 SLOV
LPF SYNC V
3
Service
Group
Fix/
Var
No. Name Description
DEF
