Sony TRINITRON KD-27FS170 - Page 71

KD-27FS170/32FS170/36FS170
KD-27FS170/32FS170/36FS170
71
KD-36FS170 MODELS ONLY
NTSC Video YUV Digital
Init Init Init Init
Data Data Data Data
Service
Group
Fix/
Var
No. Name Description
FIX
33 SLOP
LPF SYNC
3
FIX
34 SLVC
LPF SYNC VCOIN OFF
0
FIX
35 SLHC
LPF SYNC HCOIN OFF 0
FIX
36 VF50 VFREERUN 50Hz 0
FIX
37 VSET V FREQ SET 50\60 AUTO 0
VAR
1VSIZ
V RAMP SIZE
32
VAR
2VPOS
V POSITION
(
RAMP DC
)
33
VAR
3VLIN
V LINEARITY
35
VAR
4SCOR
S CORRECTION 24
VAR
5TRAP
EW TRAPESIUM
28
VAR
6PAMP
EW PIN
12
VAR
7UPIN
UPPER PIN
32
VAR
8LPIN
LOWER PIN
32
VAR
9ABLG
ABL GAIN
1
VAR
10 SCON
SUB CONTRAST LEVEL
10
VAR
11 VPW
Jum
p
Pulse Width
1
VAR
1RDRV
R DRIVE
84
VAR
2GDRV
G DRIVE when Color Tem
p
. is "Cool" and "Neutral"
76 76 68 76
VAR
3BDRV
B DRIVE when Color Tem
p
. is "Cool" and "Neutral"
91
91 97 91
VAR
4 RCUT Hardware AKB(R) CMP DATA
100
VAR
5 GCUT Hardware AKB(G) CMP DATA when Color Temp. is "Cool" and "Neutral" 55 55
VAR
5 GCUT Hardware AKB(G) CMP DATA when Color Temp. is "Cool" and "Neutral"
54 55
VAR
6 BCUT Hardware AKB(B) CMP DATA when Color Temp. is "Cool" and "Neutral" 60
60
VAR
6 BCUT Hardware AKB(B) CMP DATA when Color Temp. is "Cool" and "Neutral"
45 60
VAR
7 SCON SUB CONTRAST LEVEL 17
VAR
8 SHUE SUB TINT(HUE) 11
78 7
VAR
9 SCOL SUB COLOR LEVEL for Not NR 5
423 5
VAR
10 SBRT SUB BRIGHTNESS 11
11 14 16
VAR
11 RON R OUTPUT ON ( 0:R Output OFF 1:R Output ON ) 1
VAR
12 GON G OUTPUT ON ( 0:G Output OFF 1:G Output ON ) 1
VAR
13 BON B OUTPUT ON ( 0:B Output OFF 1:B Output ON ) 1
FIX
14 BLLV BLUE STRETCH(00:no <-> 11:deep) only Color Temp "Cool" 1
FIX
15 BLLM BLUE STRETCH Y LEREL LIMIT LEVEL 0
DEF16:9VP1
