KD-36FS170 MODELS ONLY
NTSC Video YUV Digital
Init Init Init Init
Data Data Data Data
Service
Group
Fix/
Var
No. Name Description
FIX
16 MTRX
MATRIX RATIO SELECT
1
FIX
17 AXIS
R-Y PHASE OFFSET
52
FIX
18 GYG
G-Y Gain
0
FIX
19 GYP
G-Y PHASE 0
FIX
20 SSHO SUB SHARPNESS GAIN(OVER) RF VIDEO 12
14 2 16
FIX
21 SSHP SUB SHARPNESS GAIN(PRE) RF VIDEO 17
19 13 21
FIX
22 SHPF SHRPNESS fo(00:2 CLK <-> 11:5 CLK) 0
FIX
22 SHPF SHRPNESS fo(00:2 CLK <-> 11:5 CLK)
10 1
FIX
23 SHCL SHARPNESS CORING LEVEL 1
FIX
24 SHMX SHARPNESS LIMITTER LEVEL 15
FIX
25 AKBD AKB Self Diagnostic Counter(@1sec) 5
FIX
26 AKBS AKB Switch ( 0 : AKB OFF 1 : H W AKB ON ) 1
FIX
27 REFP
AKB REFPLS timin
g(
"0"Fix when 16:9On
)
0
FIX
28 YNRC YNR LIMITER LEVEL 15
FIX
29 VYNR VYNR LIMITER LEVEL 0
FIX
30 BKON BLACK STRETCH ON 1
FIX
31 BKRC BLACK STRETCH DETECTOR TIME CONSTANT1 252
FIX
32 BKDP BLACK STRETCH START POINT 3
FIX
33 BKSP BLACK STRETCH POINT
2
VAR
34 UOFS
U IN OFFSET 32 72 78
VAR
35 VOFS
V IN OFFSET
32
76 74
FIX
36 TAKE BPF F0 UP 0
FIX
36 TAKE BPF F0 UP 00
FIX
37 TAKW BPF F0 UP WIDTH 0
FIX
37 TAKW BPF F0 UP WIDTH 00
FIX
1VMOF
VM LEVEL at "Off" Settin
g
2
FIX
2VMLO
VM LEVEL at "Low" Settin
g
5
FIX
3VMHI
VM LEVEL at "Hi
g
h" Settin
g
11
FIX
4VMDL
VM DELAY 11 11 7 11
FIX
5VMPL
VM PORALITY
1
FIX
6VMWD
VM WIDTH
0
FIX
7VMCL
VM CORING LEVEL
0
FIX
8VMMX
VM LIMITER LEVEL
15
FIX
9CKLV
COLOR KILLER VTH
1
FIX
10 CKON FORCE KILLER 0
FIX
11 VACL V APERTURE CORING LEVEL 0
FIX
12 VAGA V APERTURE GAIN LEVEL 7
FIX
13 VAMX V APERTURE LIMITER LEVEL 15
FIX
14 GAMM
GAMMA
(
00:no <-->11:dee
p)
2
