Sony TRINITRON KD-27FS170 - Page 76

KD-27FS170/32FS170/36FS170
KD-27FS170/32FS170/36FS170
76
KD-36FS170 MODELS ONLY
NTSC Video YUV Digital
Init Init Init Init
Data Data Data Data
Service
Group
Fix/
Var
No. Name Description
FIX
1
YNRS YNR ON
0
FIX 2 CLPS
CLAMP CONTROL SW
0:CLAMP OFF
1:CLAMP AUTO1 mode (usual procedure)
2:CLAMP ON mode
3: CLAMP AUTO2 mode
(
New
p
rocedure
)
1
FIX
3
VMG2 MODULATOR FEEDBACK GAIN CONTROL
1
FIX
4
CLPT CLAMP AUTO ON KEEP TIMER COUNT
(
@100ms
)
15
FIX
5
AASL C DECODER TIME CONSTANT
(
32,16,8,1H
)
2
FIX
6
BASL ACC TIME CONSTANT
0
FIX
7
ACTH ROM HYS
95
FIX
8
AVAV AVE SEL AV
3
FIX
9
B2TH B2COMP
0
FIX
10
CORL R CUTOFF lower
0
FIX
11
CORH R CUTOFF u
pp
er
1
FIX
12
COGL G CUTOFF lower when Color Tem
p
. is "Cool" and "Neutral"
0
FIX
13
COGH G CUTOFF u
pp
er when Color Tem
p
. is "Cool" and "Neutral"
1
FIX
14
COBL B CUTOFF lower when Color Tem
p
. is "Cool" and "Neutral"
0
FIX
15
COBH B CUTOFF u
pp
er when Color Tem
p
. is "Cool" and "Neutral"
1
FIX
16
ALSP ACL SPEED
0
FIX
17
ALAS ACL ATACK SPEED
146
FIX 18 ABLG ABL GAIN 4
FIX 19 AKBP AKB PULSE HEIGHT
10
FIX 20 AALG ANALOG ACL GAIN CONTROL
0
FIX 21 AALS ANALOG ACL ON/OFF CONTROL
1
FIX 22 UVDT UVIN DITHER TEST
12
FIX 23 YDT Y DITHER LEVEL
1
FIX 24 HFFR AFC1 FORCE FREERUN
0
FIX 25 HFUP H FREERUN FREQUENCY UP(700Hz)
0
FIX 26 JSWW Jump Pulse Width
0
FIX 27 XF0A VCXO FREERUN ADJUST
0
FIX 28 BGST BGP(for PLL) TIMING
16
16 6 16
FIX 29 XPHA VCXO PHASE ADJUST
8
ASICASIC
