KD-27FS170/32FS170/36FS170

KD-36FS170 MODELS ONLY

NTSC Video YUV Digital

Init Init Init Init

Data Data Data Data

Service

Group

Fix/

Var

No. Name Description

FIX 30 HRMP AFC2 TIME CONSTANT

FIX 31 RPLU REF PLL TIME CONSTANT

FIX 32 RPLB REF PLL TIME CONSTANT

FIX 33 XF0B VCXO Fo ADJUST

FIX 34 RPLS REF VCO FB LOOP SELECT

FIX 35 SSM SyncSepaMasking CONTROL 0

FIX 36 VSAG V-SAG prevent ON

FIX 37 AFC2 AFC2 GAIN CONTROL

FIX 38 XPLU ACP TIME CONSTANT

FIX 39 AAPC APC TIME CONSTANT BW SLOW

FIX 40 CDM2 V_LOGIC SW

FIX 41 MHDL BGP SEL

FIX 42 HRPP FRAMP RRAMP H OUT CONTROL RANGE

FIX 43 DSCK DS DAC CLK SW for only Not YUV (YUV:"1"Fix)

00 0

FIX 44 VPW V Pulse Wide

FIX 45 DTH DITHER THRESHOLD LEVEL CONTROL at IIC AUTOD=ON

FIX 46 YOFF Y OUTPUT MUTE

FIX 47 VSSW SYNC SLICE LEVEL(V) Wide Window

FIX 48 AF2S AFC2 timing SW

FIX 49 VSL2 Digital V_SYNC_LPF(fall)

FIX 50 VSL1 Digital V_SYNC_LPF(rise)

FIX 51 VSHE V-SHRINK MODE for AV-NoSync

FIX 52 DSCS CLOCK DIV SEL 0010

FIX 53 14HI 4fsc(Skew)CLK POLARITY

FIX 54 14HD 4fscCLK

(

Skew

)

CLK DELAY ADJUST

ASIC
