REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R4518 1-216-025-91 RES,CHIP 100 5% 1/10W
R4519 1-216-025-91 RES,CHIP 100 5% 1/10W
R4520 1-216-295-91 SHORT 0
R4521 1-216-295-91 SHORT 0
R4522 1-216-295-91 SHORT 0
R4523 1-216-295-91 SHORT 0
< CRYSTAL >
X4300 1-767-127-11 VIBRATOR, CERAMIC
< CAPACITOR >
C4367 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
< CAPACITOR >
C4367 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C4380 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
< TRANSISTOR >
Q4318 8-729-026-49 TRANSISTOR 2SA1037AK-T-146-R
< RESISTOR >
R4403 1-216-073-00 RES, CHIP 10K 5% 1/10W
R4404 1-216-073-00 RES, CHIP 10K 5% 1/10W
R4405 1-216-689-11 RES, CHIP 39K 5% 1/10W
R4406 1-216-105-91 RES, CHIP 220K 5% 1/10W
R4407 1-216-091-00 RES, CHIP 56K 5% 1/10W
4-382-854-11 SCREW (M3X10), P, SW (+)
< CAPACITOR >
C6100 1-136-165-00 FILM 0.1MF 5% 50V
C6101 1-136-165-00 FILM 0.1MF 5% 50V
C6102 1-136-165-00 FILM 0.1MF 5% 50V
C6103 1-163-205-00 CERAMIC CHIP 0.001MF 5% 50V
C6104 1-163-205-00 CERAMIC CHIP 0.001MF 5% 50V
C6105 1-126-967-11 ELECT 47MF 20% 50V
C6106 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C6108 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C6109 1-126-967-11 ELECT 47MF 20% 50V
C6110 1-126-967-11 ELECT 47MF 20% 50V
C6112 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C6113 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C6114 1-126-964-11 ELECT 10MF 20% 50V
C6115 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C6116 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C6117 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C6119 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C6120 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C6121 1-126-964-11 ELECT 10MF 20% 50V
C6122 1-126-967-11 ELECT 47MF 20% 50V
C6125 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C6126 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C6127 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C6128 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C6129 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C6131 1-126-964-11 ELECT 10MF 20% 50V
C6132 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C6199 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C6207 1-126-967-11 ELECT 47MF 20% 50V
C6208 1-126-967-11 ELECT 47MF 20% 50V
C6209 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C6210 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C6250 1-104-664-11 ELECT 47MF 20% 16V
C6251 1-216-295-91 SHORT 0
C6253 1-115-339-11 CERAMIC CHIP 0.1MF 10% 50V
C6254 1-136-177-00 FILM 1MF 5% 50V
C6255 1-136-177-00 FILM 1MF 5% 50V
C6256 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C6257 1-115-339-11 CERAMIC CHIP 0.1MF 10% 50V
C6258 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C6259 1-110-501-11 CERAMIC CHIP 0.33MF 10% 16V
C6260 1-104-664-11 ELECT 47MF 20% 16V
C6261 1-115-339-11 CERAMIC CHIP 0.1MF 10% 50V
C6262 1-136-165-00 FILM 0.1MF 5% 50V
C6263 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C6264 1-126-964-11 ELECT 10MF 20% 50V
C6306 1-126-964-11 ELECT 10MF 20% 50V
C6307 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C6350 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C6351 1-126-967-11 ELECT 47MF 20% 50V
C6353 1-115-339-11 CERAMIC CHIP 0.1MF 10% 50V
C6354 1-136-159-00 FILM 0.033MF 5% 50V
C6355 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C6356 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
E Board Variant Parts KV-28FC60/28FC60/Z
E Board Variant Parts KV-32FC60/32FC60/Z
*A-1640-369-A D1 Board, Complete
(KV-28FC60/28FC60/Z)
*A-1640-366-A D1 Board, Complete
(KV-32FC60/32FC60/Z)
D1 Board Common Parts
E D1
