115
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
C6357 1-136-165-00 FILM 0.1MF 5% 50V
C6358 1-104-329-11 CERAMIC CHIP 0.1MF 10% 50V
C6359 1-104-329-11 CERAMIC CHIP 0.1MF 10% 50V
C6360 1-107-714-11 ELECT 10MF 20% 50V
C6361 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C6362 1-164-182-11 CERAMIC CHIP 0.0033MF 10% 50V
C6363 1-104-665-11 ELECT 100MF 20% 25V
C6364 1-136-347-11 FILM 0.0047MF 5% 630V
C6365 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C6367 1-104-329-11 CERAMIC CHIP 0.1MF 10% 50V
C6368 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C6370 1-136-347-11 FILM 0.0047MF 5% 630V
C6373 1-136-153-00 FILM 0.01MF 5% 50V
C6374 1-129-716-00 FILM 0.015MF 5% 630V
C6375 1-102-110-00 CERAMIC 220PF 10% 50V
C6376 1-104-664-11 ELECT 47MF 20% 16V
C6377 1-128-551-11 ELECT 22MF 20% 25V
C6378 1-115-339-11 CERAMIC CHIP 0.1MF 10% 50V
C6380 1-136-165-00 FILM 0.1MF 5% 50V
C6381 1-126-960-11 ELECT 1MF 20% 50V
C6385 1-104-664-11 ELECT 47MF 20% 25V
C6386 1-104-664-11 ELECT 47MF 20% 25V
C6388 1-126-964-11 ELECT 10MF 20% 50V
C6389 1-126-964-11 ELECT 10MF 20% 50V
C6392 1-104-664-11 ELECT 47MF 20% 25V
C6401 1-126-964-11 ELECT 10MF 20% 50V
C6402 1-107-714-11 ELECT 10MF 20% 50V
C6407 1-136-161-00 FILM 0.047MF 5% 50V
C6408 1-136-161-00 FILM 0.047MF 5% 50V
C6409 1-126-964-11 ELECT 10MF 20% 50V
< CONNECTOR >
CN6502 *1-568-881-51 PIN, CONNECTOR 6P
CN6600 *1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
CN6601 1-695-302-11 CONNECTOR, BOARD TO BOARD 50P
CN6622 *1-568-878-51 PIN, CONNECTOR 3P
CN6633 *1-568-878-51 PIN, CONNECTOR 3P
< DIODE >
D6102 8-719-914-43 DIODE DAN202K
D6104 8-719-914-43 DIODE DAN202K
D6105 8-719-914-43 DIODE DAN202K
D6107 8-719-914-43 DIODE DAN202K
D6108 8-719-921-40 DIODE MTZJ-4.7C
D6127 8-719-914-43 DIODE DAN202K
D6128 8-719-914-43 DIODE DAN202K
D6129 8-719-914-43 DIODE DAN202K
D6198 1-535-303-00 LEAD, JUMPER (5.0MM)
D6253 8-719-911-19 DIODE 1SS119-25
D6254 1-535-303-00 LEAD, JUMPER (5.0MM)
D6255 8-719-914-43 DIODE DAN202K
D6350 8-719-914-43 DIODE DAN202K
D6351 8-719-914-43 DIODE DAN202K
D6352 8-719-914-43 DIODE DAN202K
D6353 8-719-987-87 DIODE ERA85-009
D6354 8-719-914-43 DIODE DAN202K
D6355 8-719-914-43 DIODE DAN202K
D6358 8-719-914-43 DIODE DAN202K
D6359 8-719-302-43 DIODE EL1Z
D6401 8-719-914-43 DIODE DAN202K
D6402 8-719-982-03 DIODE MTZJ-3.6A
D6403 8-719-921-63 DIODE MTZJ-7.5B
D6404 8-719-914-43 DIODE DAN202K
D6405 8-719-921-63 DIODE MTZJ-7.5B
< IC >
IC6100 8-759-450-95 IC LM393N
IC6101 8-759-450-95 IC LM393N
IC6102 8-759-701-50 IC NJM3404AD
IC6103 8-759-450-95 IC LM393N
IC6250 8-759-478-66 IC CXA8070P
IC6251 8-759-903-16 IC LM318P
IC6302 8-752-072-94 IC CXA1875AM-T4
IC6350 8-759-008-70 IC LM358N
IC6351 8-759-450-95 IC LM393N
IC6352 8-759-450-95 IC LM393N
IC6353 8-759-231-53 IC TA7805S
IC6354 8-759-325-48 IC CA0005AD
IC6355 8-759-008-70 IC LM358N
IC6356 8-759-822-38 IC LA6510
< FILTER >
LF6350 1-406-989-21 INDUCTOR 10MMH
LF6351 1-406-989-21 INDUCTOR 10MMH
< IC LINK >
PS6376 £ 1-532-637-00 LINK, IC 1A (ICP-N25)
< TRANSISTOR >
Q6100 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6104 8-729-120-28 TRANSISTOR 2SC1623-L5L6
