116
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
Q6105 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6106 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6107 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6108 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6110 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6112 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6113 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6118 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6119 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6120 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6122 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6123 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6125 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6126 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6127 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6128 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6129 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6201 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6202 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6250 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6251 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6252 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6253 8-729-045-04 TRANSISTOR 2SC5511
Q6254 8-729-045-05 TRANSISTOR 2SA005
Q6350 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6351 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q6352 8-729-140-97 TRANSISTOR 2SB734-34
Q6353 8-729-140-97 TRANSISTOR 2SB734-34
Q6354 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6356 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6358 8-729-038-83 TRANSISTOR 2SK2251-01-F19
Q6401 1-801-806-11 TRANSISTOR DTC144EKA
Q6402 1-801-806-11 TRANSISTOR DTC144EKA
Q6403 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6404 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6405 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q6455 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6465 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R6100 1-216-033-00 RES,CHIP 220 5% 1/10W
R6101 1-216-033-00 RES,CHIP 220 5% 1/10W
R6102 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6103 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6104 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6105 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6106 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6109 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R6110 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R6111 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6112 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6113 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6114 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6115 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6116 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6117 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6118 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6119 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6120 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6121 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6122 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6123 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6124 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6125 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6126 1-216-037-00 RES,CHIP 330 5% 1/10W
R6128 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R6129 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R6131 1-216-037-00 RES,CHIP 330 5% 1/10W
R6132 1-216-037-00 RES,CHIP 330 5% 1/10W
R6133 1-216-037-00 RES,CHIP 330 5% 1/10W
R6135 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
R6136 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R6137 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R6138 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R6139 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R6140 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6143 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6146 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R6148 1-216-295-91 SHORT 0
R6149 1-216-025-91 RES,CHIP 100 5% 1/10W
R6155 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R6160 1-216-295-91 SHORT 0
R6162 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6165 1-216-699-91 METAL CHIP 100K 0.50% 1/10W
R6168 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R6169 1-216-699-91 METAL CHIP 100K 0.50% 1/10W
R6170 1-216-037-00 RES,CHIP 330 5% 1/10W
R6171 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6177 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R6180 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6182 1-216-089-91 RES,CHIP 47K 5% 1/10W
R6183 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6188 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
