– 20 –
KV-G21MW3/G21QW3
RM-869
Data Range
Adjustment Item Table
No. Item Initial Function Note for Different Data Device/Category Register
(OSD) Max. Min. Data (Slave Address) No. (bit)
35 BKP 3F 00 00 Picture Data at Blanking OFF Other Control
36 ODL FF 00 10 Power ON Delay
37 OFR 0F 00 00
RGB Output Time (STBY OFF)
38 OFM 0F 00 00 RGB Output Time (AC OFF)
39 OSH 3F 00 0A OSD H Position
3A DKS 1 0 1 D/K Stereo enable/disable
3B MUT 1 0 0 Muting on/off at No Sync
3C ABL 1 0 0 Bright ABL Switch
3D SCM 1 0 0 SECAM Trap active/ inactive
3E FBT 1 0 1 FBT L/S C /M Strict/plain
3F OP0 FF 00 2F Optional Flags 0 (see below)
40 OP1 FF 00 0F Optional Flags 1 (see below)
41 OP2 FF 00 00 Optional Flags 2 (see below)
