– 21 –
KV-G21MW3/G21QW3
RM-869
Option Note
Item HCO EVG SBL PRD – – – VID
G21MW3 0 0 0 0 0 0 0 0
G21QW3 0 0 0 0 0 0 0 0
HCO EHT Tracking Mode 1 = on V and E–W. 0 = only on V 0A (7)
EVG Enable Vertical Guard 1 = enable. 0 = disable 0A (6)
SBL Service Blanking 1 = active. 0 = inactive 0B (7)
PRD Over-voltage Protection Detection 1 = enable. 0 = disable 0B (6)
VID Video Ident Mode 1 = not for ø1-loop 0 = for ø1-loop 09 (7)
AV Input 0 0 no AV input model 0 1 1 AV input model
1 0 2 AV input model 1 1 2 AV input and RGB input model
No TOP (for teletext model) 1 = only FLOF available. 0 = both FLOF and TOP available
AV MUT 1 = AV multi is always muted if no signal input. 0 = not muted always
Other optional bits are effective if set to 1.
XTAL SEL 0 0 only 4.43 XTAL 0 1 only 3.58 XTAL
1 0 (not used) 1 1 both 4.43 and 3.58 XTAL
1 V-Curve (for monaural model)
1 = using common volume curve for every mode and every TV system
0 = another volume curve available for video mode and M system
HDEV 1 = High Deviation Mode switch available. 0 = not available
No NICAM 1 = NICAM search is disabled in any TV system, 0 = NICAM search operates
Other optional bits are effevctive if set to 1.
No Bal. (for AV stereo model) 1 = no balance in analog select items. 0 = balance included
Other optional bits are effective if set to 1.
Hotel TV mode should be switched with remote commander from STBY condition as below.
Hotel TV on : push “display”. “8”. “vol +” and “power” sequentially
Hotel TV off : push “display”. “8”. “vol –” and “power” sequentially
NOTE
• Note for Different Data Those are the standard data values written on the microprocessor. Therefore, the data values of
the modes are stored respectively in the memory.
In case of a device replacement, adjustment by rewriting the data value is necessary for some
items.
• 50.............. 50 Hz data
• 60.............. 60 Hz data
• Note for Different Data listed on the adjustment item table are reference values, therefore it is different for every model.
Item No 13 VPX
Item – – No Bal. TV Out Hotel VM D.B.F.B. Thai Bil.
G21MW3 0 0 0 0 0 0 0 0
G21QW3 0 0 0 0 0 0 0 0
Item No. 41 OP2
Item No NICAM – HDEV 1 V-Curve XTAL SEL SECAM 2nd Lang.
G21MW3 0 0 0 0 1 1 1 1
G21QW3 0 0 0 0 0 0 1 1
Item No. 40 OP1
Item No TOP AV input AVMUT B/G I D/K M
G21MW3 0 0 1 0 1 1 1 1
G21QW3 0 0 1 0 1 0 0 0
Item No. 3F OP0
To Next Page
