– 46 –
REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK
KV-G21MW3/G21QW3
RM-869
C241 1-126-942-61 ELECT 1000UF 20.00%25V
C242 1-163-021-91 CERAMIC CHIP 0.01UF 10.00%50V
C243 1-126-964-11 ELECT 10UF 20.00%50V
C244 1-126-942-61 ELECT 1000UF 20.00%25V
C246 1-126-964-11 ELECT 10UF 20.00%50V
C247 1-126-942-61 ELECT 1000UF 20.00%25V
C252 1-126-961-11 ELECT 2.2UF 20.00%50V
C253 1-104-665-11 ELECT 100UF 20.00%16V
C254 1-163-037-11 CERAMIC CHIP 0.022UF 10.00%50V
C255 1-163-037-11 CERAMIC CHIP 0.022UF 10.00%50V
C257 1-136-167-00 MYLAR 0.15UF 5.00% 50V
C258 1-136-167-00 MYLAR 0.15UF 5.00% 50V
C300 1-104-664-11 ELECT 47UF 20.00%16V
C301 1-126-964-11 ELECT 10UF 20.00%50V
C304 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C305 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C306 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C307 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C308 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C309 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C310 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C311 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
(KV-G21MW3)
C312 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C313 1-104-665-11 ELECT 100UF 20.00%16V
C314 1-164-161-11 CERAMIC CHIP 0.0022UF 10.00%50V
C315 1-107-823-11 CERAMIC CHIP 0.47UF 10.00%16V
C316 1-102-125-00 CERAMIC 0.0047UF 10.00%50V
C317 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C319 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C320 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C321 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C322 1-216-295-91 SHORT 0
C323 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C324 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C325 1-163-093-00 CERAMIC CHIP 10PF 5.00% 50V
C326 1-163-095-00 CERAMIC CHIP 12PF 5.00% 50V
C327 1-163-093-00 CERAMIC CHIP 10PF 5.00% 50V
C328 1-163-021-91 CERAMIC CHIP 0.01UF 10.00%50V
C329 1-163-016-00 CERAMIC CHIP 0.0039UF 10.00%50V
C330 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C331 1-126-964-11 ELECT 10UF 20.00%50V
C332 1-136-165-00 MYLAR 0.1UF 5.00% 50V
C333 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C334 1-164-182-11 CERAMIC CHIP 0.0033UF 10.00%50V
C335 1-102-973-00 CERAMIC 100PF 5.00% 50V
C336 1-126-964-11 ELECT 10UF 20.00%50V
C337 1-104-665-11 ELECT 100UF 20.00%16V
C338 1-107-823-11 CERAMIC CHIP 0.47UF 10.00%16V
C339 1-163-121-00 CERAMIC CHIP 150PF 5.00% 50V
C340 1-163-021-91 CERAMIC CHIP 0.01UF 10.00%50V
C341 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C342 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C344 1-126-964-11 ELECT 10UF 20.00%50V
C349 1-126-964-11 ELECT 10UF 20.00%50V
C350 1-104-664-11 ELECT 47UF 20.00%16V
C351 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C352 1-164-489-11 CERAMIC CHIP 0.22UF 10.00%16V
C358 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C359 1-104-665-11 ELECT 100UF 20.00%16V
C361 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C362 1-163-235-11 CERAMIC CHIP 22PF 5.00% 50V
C367 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C368 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C369 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C370 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C374 1-104-664-11 ELECT 47UF 20.00%10V
C375 1-104-664-11 ELECT 47UF 20.00%10V
C376 1-107-823-11 CERAMIC CHIP 0.47UF 10.00%16V
C402 1-163-021-91 CERAMIC CHIP 0.01UF 10.00%50V
C403 1-126-965-11 ELECT 22UF 20.00%50V
C405 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00%50V
C406 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00%50V
C407 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00%50V
C408 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00%50V
C409 1-163-109-00 CERAMIC CHIP 47PF 5.00% 50V
(KV-G21MW3)
C410 1-163-103-00 CERAMIC CHIP 27PF 5.00% 50V
C411 1-163-113-00 CERAMIC CHIP 68PF 5.00% 50V
C412 1-163-113-00 CERAMIC CHIP 68PF 5.00% 50V
(KV-G21MW3)
C413 1-104-665-11 ELECT 100UF 20.00%16V
C414 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C415 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00%50V
C416 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
(KV-G21MW3)
C417 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
(KV-G21MW3)
C418 1-163-131-00 CERAMIC CHIP 390PF 5.00% 50V
(KV-G21MW3)
C419 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
(KV-G21MW3)
C420 1-104-664-11 ELECT 47UF 20.00%16V
C422 1-163-129-00 CERAMIC CHIP 330PF 5.00% 50V
(KV-G21MW3)
C423 1-163-129-00 CERAMIC CHIP 330PF 5.00% 50V
C424 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C501 1-102-228-00 CERAMIC 470PF 10.00%500V
C523 1-104-665-11 ELECT 100UF 20.00%16V
C548 1-106-220-00 MYLAR 0.1UF 10.00%100V
C551 1-126-968-11 ELECT 100UF 20.00%35V
C552 1-126-968-11 ELECT 100UF 20.00%35V
C553 1-163-019-00 CERAMIC CHIP 0.0068UF 10.00%50V
C554 1-102-244-00 CERAMIC 220PF 10.00%500V
C555 1-101-804-00 CERAMIC 10PF 5.00% 500V
C562 1-104-665-11 ELECT 100UF 20.00%16V
C602 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C603 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C604 1-117-752-11 ELECT(BLOCK) 330UF 20.00%450V
C605 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C606 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C607 1-161-830-00 CERAMIC 0.0047UF 99% 500V
C608 1-104-332-11 CERAMIC 470PF 10.00%2KV
C609 1-123-024-21 ELECT 33UF 160V
C611 ! 1-113-900-11 CERAMIC 470PF 10.00%250V
C613 1-102-824-00 CERAMIC 470PF 5.00% 50V
