– 45 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
KV-G21MW3/G21QW3
RM-869
* A-1299-259-A A BOARD COMPLETE (KV-G21MW3)
* A-1299-258-A A BOARD COMPLETE (KV-G21QW3)
********************
1-533-223-11 CLIP, FUSE
* 4-059-711-01 HOLDER, FBT
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
<CAPACITOR>
C001 1-163-011-11 CERAMIC CHIP 0.0015UF 10.00%50V
C002 1-126-965-11 ELECT 22UF 20.00%50V
C003 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
(KV-G21MW3)
C004 1-126-961-11 ELECT 2.2UF 20.00%50V
C006 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C007 1-126-959-11 ELECT 0.47UF 20.00%50V
C008 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C009 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C010 1-163-037-11 CERAMIC CHIP 0.022UF 10.00%50V
C011 1-104-664-11 ELECT 47UF 20.00%16V
C012 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
(KV-G21MW3)
C013 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C014 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C015 1-101-884-00 CERAMIC 56PF 5.00% 50V
C016 1-101-884-00 CERAMIC 56PF 5.00% 50V
C017 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C018 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C019 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C020 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C021 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C022 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C023 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C024 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C025 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C026 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C027 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C028 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C029 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C034 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C035 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C036 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C037 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C038 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C040 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C042 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C044 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C045 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C046 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C047 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C048 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C049 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C050 1-126-960-11 ELECT 1UF 20.00%50V
C051 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C052 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C053 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C054 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C055 1-126-925-11 ELECT 470UF 20.00%10V
C056 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C057 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C058 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C059 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C060 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C061 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C064 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C072 1-126-925-11 ELECT 470UF 20.00%10V
C074 1-163-001-11 CERAMIC CHIP 220PF 10.00%50V
C101 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00%50V
C103 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C105 1-104-665-11 ELECT 100UF 20.00%16V
C106 1-126-964-11 ELECT 10UF 20.00%50V
C108 1-126-767-11 ELECT 1000UF 20.00%16V
C109 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00%50V
C111 1-163-009-11 CERAMIC CHIP 0.001UF 10.00%50V
C114 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C115 1-163-093-00 CERAMIC CHIP 10PF 5.00% 50V
C116 1-136-165-00 MYLAR 0.1UF 5.00% 50V
C117 1-163-117-00 CERAMIC CHIP 100PF 5.00% 50V
C118 1-126-965-11 ELECT 22UF 20.00%50V
C119 1-163-021-91 CERAMIC CHIP 0.01UF 10.00%50V
C120 1-130-493-00 MYLAR 0.068UF 5.00% 50V
C121 1-130-493-00 MYLAR 0.068UF 5.00% 50V
C122 1-104-665-11 ELECT 100UF 20.00%16V
C124 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C125 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C127 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C128 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V
C220 1-126-965-11 ELECT 22UF 20.00%50V
C233 1-104-664-11 ELECT 47UF 20.00%16V
C234 1-104-664-11 ELECT 47UF 20.00%16V
C235 1-104-665-11 ELECT 100UF 20.00%16V
C236 1-104-666-11 ELECT 220UF 20.00%25V
C237 1-104-665-11 ELECT 100UF 20.00%16V
C238 1-136-167-00 MYLAR 0.15UF 5.00% 50V
C239 1-104-665-11 ELECT 100UF 20.00%16V
C240 1-136-167-00 MYLAR 0.15UF 5.00% 50V
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF : µF, PF : µµF
COILS
• MMH : mH, UH : µH
• Items marked " ∗ " are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when or-
dering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
