– 5 –
KV-HS29M61/M90/M91, HS34M61/M90/M91, HS38M61/M90/M91
RM-997
2. DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT
Diagnostic Item Flash Count*
+B overcurrentovervoltage 2 times
+B overvoltage 3 times
V deflection stop 4 times
White balance failure 5 times
High voltage protecter 6 times
Audio protection 7 times
* One flash count is not used for self-diagnostic.
3. STOPPING THE STANDBY/TIMER FLASH
Turn off the power switch on the TV main unit or unplug the power cord from the outlet to stop the STANDBY/TIMER lamp
from flashing.
Lamp ON 0.3 sec.
Lamp OFF 3 sec.
Lamp OFF 0.3 sec.
2 times
5 times
4 times
5 times
6 times
7 times
STANDBY/SLEEP lamp
• One flash count is not used for self-diagnostic.
To Next Page
