KV-HS29M61/M90/M91, HS34M61/M90/M91, HS38M61/M90/M91
RM-997
– 133 –
-------------------------------------------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
• The components identified by in this manual
have been carefully factory-selected for each
set in order to satisfy regulations regarding X-
ray radiation. Should replacement be required,
replace only with the value originally used.
• Items marked " * " are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise noted.
RESISTORS
• All resistors are in ohms
SECTION 7
ELECTRICAL PARTS LIST
* A-1300-864-A A BOARD, COMPLETE (KV-HS34M90)
**********************
* A-1300-872-A A BOARD, COMPLETE (KV-HS38M90)
*********************
* A-1300-899-A A BOARD, COMPLETE (KV-HS29M90)
*********************
* A-1300-907-A A BOARD, COMPLETE (KV-HS34M91)
**********************
* A-1300-908-A A BOARD, COMPLETE (KV-HS34M61)
*********************
* A-1300-931-A A BOARD, COMPLETE (KV-HS38M61)
*********************
* A-1300-932-A A BOARD, COMPLETE (KV-HS38M91)
**********************
* A-1300-973-A A BOARD, COMPLETE (KV-HS29M61)
*********************
* A-1300-975-A A BOARD, COMPLETE (KV-HS29M91)
*********************
* 4-042-408-01 PIN, COATING LEAD
4-382-854-11 SCREW (M3X10), P, SW (+)
<CAPACITOR>
C001 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C002 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C003 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C004 1-126-947-11 ELECT 47UF 20.00% 16V
C005 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C006 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C007 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C008 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C009 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C010 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C011 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C012 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C014 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C016 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C017 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C018 1-126-935-11 ELECT 470UF 20.00% 10V
C020 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 25V
C022 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C024 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C025 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C026 1-128-551-11 ELECT 22UF 20.00% 25V
C027 1-126-964-11 ELECT 10UF 20.00% 50V
C028 1-126-933-11 ELECT 100UF 20.00% 16V
C029 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C030 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C031 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C032 1-115-467-11 CERAMIC CHIP 0.22UF 10.00% 10V
C033 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C034 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C035 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C036 1-128-551-11 ELECT 22UF 20.00% 25V
C043 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C103 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C104 1-126-933-11 ELECT 100UF 20.00% 16V
C105 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C106 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C107 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C108 1-126-933-11 ELECT 100UF 20.00% 16V
C109 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C110 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C111 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C112 1-126-933-11 ELECT 100UF 20.00% 16V
C113 1-126-947-11 ELECT 47UF 20.00% 16V
C114 1-126-967-11 ELECT 47UF 20.00% 50V
C105 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C118 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C123 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C124 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C125 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V
C126 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C127 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C128 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C129 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C130 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C131 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C132 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C133 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C134 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C135 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C136 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C137 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C138 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C139 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C141 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C142 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C143 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C144 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C145 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C146 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C147 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C148 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C151 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C154 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C162 1-126-394-11 ELECT CHIP 10UF 20.00% 16V
C163 1-126-394-11 ELECT CHIP 10UF 20.00% 16V
C164 1-126-390-11 ELECT CHIP 22UF 20.00% 6.3V
C165 1-124-779-11 ELECT CHIP 10UF 20.00% 16V
C166 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C176 1-126-933-11 ELECT 100UF 20.00% 16V
C178 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C301 1-126-767-11 ELECT 1000UF 20.00% 16V
C326 1-126-964-11 ELECT 10UF 20.00% 50V
C1212 1-126-943-11 ELECT 2200UF 20.00% 25V
C1213 1-126-943-11 ELECT 2200UF 20.00% 25V
C1214 1-126-055-11 ELECT 470UF 20.00% 50V
C1215 1-126-055-11 ELECT 470UF 20.00% 50V
C1216 1-126-943-11 ELECT 2200UF 20.00% 25V
C1217 1-126-943-11 ELECT 2200UF 20.00% 25V
A
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
• CAPACITORS
PF : µµ F
• There are some cases the reference number on
one board overlaps on the other board.
Therefore, when ordering parts by the reference
number, please include the board name.
NOTE:
When indicating parts by reference number,
please include the board name.
REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- ------------------- -------------
