REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- -------------------- -------------
REF. NO. PART NO. DESCRIPTION REMARK
------------ ------------- -------------------- -------------
1 X-4040-663-1 BEZEL ASSY(KV-HS38) 1-10
X-4040-662-2 BEZEL ASSY(KV-HS34) 1-10
X-4040-828-2 BEZEL ASSY(KV-HS29) 1-10
2 4-090-356-01 BUTTON, MULTI (A)
3 4-090-357-01 BUTTON, MULTI (B)
4 4-090-361-01 HOLDER, ORNAMENT (MS)
5 4-036-405-11 SPRING, COMPRESSION
6 4-090-358-11 BUTTON, POWER
7 4-090-360-01 ORNAMENT (MS)
8 4-090-355-11 DOOR
9 4-076-673-03 DAMPER, DOOR
10 4-072-630-01 CUSHION, DOOR
11 4-067-221-03 CLIP, DGC(KV-HS38)
12 X-4040-827-2 CABINET ASSY(KV-HS29)
X-4040-651-2 CABINET, ASSY(KV-HS38)
X-4040-650-3 CABINET, ASSY(KV-HS34)
13 1-456-057-11 COIL, LANDING CORRECTION
(KV-HS38)
1-456-056-11 COIL, LANDING CORRECTION
(KV-HS34)
1-456-058-11 COIL, LANDING CORRECTION
(KV-HS29)
14 4-090-392-01 CRT SUPPORTER (KV-HS38)
4-090-385-01 CRT SUPPORTER (KV-HS34)
4-091-002-01 CRT SUPPORTER (KV-HS29)
15 4-063-935-21 CUSHION (50X550), DGC (KV-HS29)
* 4-074-513-01 CUSHION (L), DGC (KV-HS34/38)
16 ! 8-735-122-05 CRT 34RFEN (KV-HS34M61)
! 8-735-125-05 CRT 29RFEN (KV-HS29M90)
! 8-735-126-05 CRT 34RFEN (KV-HS34M91)
! 8-735-116-05 CRT 34RFN (KV-HS34M90)
! 8-735-124-05 CRT 38RFN (KV-HS38M90)
! 8-735-130-05 CRT 38RFEN (KV-HS38M91)
! 8-735-131-05 CRT 38RFEN (KV-HS38M61)
! 8-735-139-05 CRT 38RFEN (KV-HS29M61/M91)
17 4-046-765-12 SCREW, TAPPING 7+CROWN WASHER
18 ! 1-451-560-11 DEFLECTION YOKE Y29SEC-T
(KV-HS29)
! 8-451-532-11 DEFLECTION YOKE Y34RFC-M
(KV-HS34)
! 8-451-533-11 DEFLECTION YOKE Y38RFC-M
(KV-HS38)
19 1-456-351-21 COIL, NA ROTATION(KV-HS38)
1-456-351-11 COIL, NA ROTATION(KV-HS29/34)
20 2-163-920-01 PLATE, TLH CORRECTION
(KV-HS34/38M90)
21 4-061-369-01 HOLDER, DEGAUSE COIL (KV-HS38)
* 4-054-297-01 HOLDER, DGC (KV-HS34)
22 4-051-734-42 PIECE B(120), CONV, CORRECT
23 1-452-032-00 MAGNET,DISC
24 1-452-094-00 CIRCULAR DISC MAGNET B
25 4-369-318-61 SPRING, TENSION (KV-HS29)
4-065-852-21 SPRING, TENSION (KV-HS34/38)
26 * A-1401-747-A V BOARD, MOUNT (KV-HS34/38)
* A-1401-883-A V3 BOARD, MOUNT (KV-HS29)
27 ! 8-453-022-21 NA2920-M2 (KV-HS29)
! 8-453-009-21 NA325-M2 (KV-HS34/38)
28 * A-1401-746-A C1 BOARD, MOUNT (KV-HS34/38)
* A-1401-882-A C1 BOARD, MOUNT (KV-HS29)
29 ! 1-456-059-11 COIL, DEGAUSS (WITH LCC)
(KV-HS38)
! 1-456-061-11 COIL, DEGAUSS (WITH LCC)
(KV-HS34)
! 1-456-063-11 COIL, DEGAUSS (WITH LCC)
(KV-HS29)
30 4-061-369-01 HOLDER, DEGAUSE COIL
(KV-HS29M61/M91)
4-064-883-03 HOLDER, DEGAUSE COIL
(KV-HS29M90)
31 * 4-062-970-01 CLIP (29RSN), DGC (KV-HS29)
32 4-067-221-03 CLIP, DGC (KV-HS34)
33 * 4-074-512-01 CUSHION (S), DGC
34 ! 1-456-059-21 COIL, DEGAUSS (WITH LCC)
(KV-HS38)
! 1-456-061-21 COIL, DEGAUSS (WITH LCC)
(KV-HS34)
! 1-456-063-21 DGC WITH LCC (WITH LCC)
(KV-HS29)
#1 7-685-648-79 +BVTP 3X12
#2 7-685-663-79 +BVTP 4X16
