Sony TRINITRON KV-M1620U - Troubleshooting; Specifications

Troubleshooting
Problems
with
and
sound
quality
can
often
be
solved
by
checking
the
symptom
in
the
list
below
and
by
following
the
suggestions.
Symptom
Checking and solution
No picture (screen not lit), « Connect the set to a working outlet
nosound
+ Press the power switch.
- Ifthe standly indicator shines red, press the TV button © on
the Commander.
Check the aerial connection.
Poor or no picture (screen not lit)
but sound good
Adjust @ « and @ bypressing the 23 or—button after selecting
with the @ button.
Good picture, but no sound
Press —<1+.
If & is displayed on the screen, press % on the
Remote Commander.
No colour for colour programmes
Adjust @ with the button after selecting with the @ button.
Press >-< .
Snow and noise
Check the aerial connections.
Dotted lines or stripes
Double images or “ghosts”
Specifications
Television system
Sound output
This may be caused by local interference (e.g. cars, neon signs
hairdriers). Adjust the aerial for minimum interference.
This may be caused by reflections from nearby mountains or
building. A highly directional outdoor aerial may improve
the picture.
5 W (music power)
Colour system
PAL
Channels coverage
|
KV-M1620U/KV-M1621U:
Channels UHF 21-69
KV-M1620L:
Channels VHF A-J, S1-S20
UHF 21-69
Power consumption
Picture tube
Black Trinitron tube 90-degree
deflection approx. 40.1 cm. (16”)
(Approx. 37 cm. picture
measured diagonally)
Dimensions
KV-M1620U 67W
KV-M1621U 72,5W
KV-M1620L 54Wh
Approx.
399 x 365 x 413 mm.
(w/h/d)
Weight
21-pin connector: CENELEC
standard RGB
Input
Audio/Video input jacks
phono jacks
12
Headphones Jack: minijack
Supplied
accessories
KV-M1620U
KV-M1621U. - 13kg
KV-M1620L_ 12,5kg
12,5kg
RM-694 Remote
Commander (1)
R6 batteries IEC
designation (2)
KV-M1620L:
VHF telescopic antenna (1)
KV-M1620U/KV-M1621U:
UHF loop antenna (1)
Aerial connector (with
built-in 300 - 75 ohm
matching transformer)
Design and specifications are subject to change
without notice.
